3/398 ABB MOTOR PROTECTION AND CONTROL

—

AF190, AF205 4-pole contactors
Dimensions

280 11.02" 152.5 6.00"
03

196 7.72"

AF190, AF205-40-11
+ VM19 mechanical interlocking unit

4 X
70 2.76" 70 2.76" 70 2.76" M5 10-24 UNC

165 6.50"

AF190, AF205
+ VM19 mechanical interlocking unit

1SFC101229C0201 - Rev. A

Main dimensions mm, inches
