ABB MOTOR PROTECTION AND CONTROL 2/35

—
Accessories

MS116, MS132, MS165, MO132, MO165, MS132-T, MS132-K, MS132-KT 02

1SBC101208F0014 Manual motor starters and MS132-T can be equipped with auxiliary contacts for lateral/front
mounting, signaling contacts for lateral mounting, undervoltage releases and shunt trips.
Two different signaling contacts are available. The accessories can be fitted wiring free and
without tools. A variety of combinations is possible as required for the application. The auxiliary
contacts change position with the main contacts. The signaling contact SK1 signals tripping
regardless if it was caused by short-circuit or overload. The signaling contact CK1 signals tripping
HKF1-11 in case it was caused by short-circuit. Undervoltage releases are used for remote tripping of the
manual motor starters, specially for emergency stop circuits. Shunt trips release the manual
motor starters used for remote tripping. These main accessories are suitable throughout the
MS116/MS132/MS165-range.
Suitable for Auxiliary Auxiliary Description Type Order code Pkg Weight
contacts contacts qty (1 pce)
N.O. N.C. kg
1SBC101209F0014 Auxiliary contacts – mountable on the front

MS116, MS132,
MS165, MO132, 1 1 1 0 HKF1-11 1SAM201901R1001 10 0.015
1SAM201901R1003
0.013
HKF1-10
10
MO165, MS132-T, 0 1 HKF1-01 1SAM201901R1004 10 0.013
HK1-11
MS132-K, MS132-KT 2 0 HKF1-20 1SAM201901R1002 10 0.015
Auxiliary contacts – mountable on the right
MS116, MS132, 1 1 max. 2 pieces HK1-11 1SAM201902R1001 2 0.035
MS165, MO132, 2 0 max. 2 pieces HK1-20 1SAM201902R1002 2 0.035
MO165, MS132-T, 0 2 max. 2 pieces HK1-02 1SAM201902R1003 2 0.035
MS132-K, MS132-KT
MS116, MS132, 2 0 max. 2 pieces HK1-20L 1SAM201902R1004 2 0.035
with leading contacts
1SBC101210F0014 MS132-K, MS132-KT
MO132, MS132-T,
Signaling contacts – mountable on the right
MS116, MS132, 1 1 for tripped alarm SK1-11 1SAM201903R1001 2 0.035
SK1-11 MS165, MO132, 2 0 for tripped alarm SK1-20 1SAM201903R1002 2 0.035
MO165, MS132-T, 0 2 for tripped alarm SK1-02 1SAM201903R1003 2 0.035
MS132-K, MS132-KT
MS132, MS165, 1 1 for short-circuit alarm CK1-11 1SAM301901R1001 2 0.035
MS132-T, MS132-K, 2 0 for short-circuit alarm CK1-20 1SAM301901R1002 2 0.035
MS132-KT 0 2 for short-circuit alarm CK1-02 1SAM301901R1003 2 0.035
Note : For BEA connecting links with AF, AS and B mini contactors please refer to chapter 3, 4 and 5.
1SBC101286F0014

CK1-11

42.1 1.66" 1.77" 45 2.83" 72 3.54" 90

9 0.35" 5.5 0.22" 27.8 1.09"
42.3 1.67"
68.8 2.71" 2CDC131050C0201 - Rev. B
HK1
Main dimensions mm, inches
