MG-CPM terminal block markers
Blank markers for SNK, SNA and Solution series

Description

–– Available in different versions to suit all ABB terminal block formats,
–– Partially printed marker cards may be re-used to avoid wastage,
–– Made of halogen free self-extinguishing polycarbonate,
–– Refer to MG3 markers' selection guide for ABB terminal blocks and end stop markers to find the suitable

marker for your needs.

3 1SNC160131F0014 Main technical data Flammability Temperature range
V0 -40°C to +140°C -40°F to +284°F
MG-CPM-13 Material
Polycarbonate

Ordering details

Spacing Dimensions Nb. of Color Type Order code SW Pkg Weight
markers code marker (1 marker) g
per card
mm in mm in

SNK series terminal block markers

MG-CPM-13

Individual markers for SNK series terminal blocks, can be strip mounted when marker and terminal block spacing are equal.

5.2 0.205 5 x 12 0.197 x 0.472 56 White MG-CPM-13 41790 1SNB041790R0512 113 1960 0.20

Yellow MG-CPM-13 41740 1SNB041740R0512 113 1960 0.20

6 0.236 6 x 12 0.236 x 0.472 48 White MG-CPM-13 41791 1SNB041791R0612 114 1680 0.30

Yellow MG-CPM-13 41741 1SNB041741R0612 114 1680 0.30

Support plate MG2-ETB 991016 1SNB991016R0000 1 100.00
Included in the MG3 Kit

SNA and Solution series terminal block markers

MG-CPM-01

Individual markers, can be strip mounted when marker and terminal block spacing are equal.

5.1 0.201 5 x 7 0.197 x 0.276 56 White MG-CPM-01 41094 1SNB041094R0507 13 1960 0.20
1 149.00
Support plate MG2-MTB 991008 1SNB991008R0000
Purchased separately 1960 0.20
1 120.00
MG-CPM-03
1120 0.30
Individual markers, can be strip mounted when marker and terminal block spacing are equal. 1120 0.40
1344 0.20
5 0.197 5 x 10 0.197 x 0.394 56 White MG-CPM-03 41291 1SNB041291R0510 25 1 120.00

Support plate MG2-QTB 991011 1SNB991011R0000 1960 0.40
Included in the MG3 Kit 1 151.00

MG-CPM-04 1960 0.20
1 151.00
Individual markers, can be strip mounted when marker and terminal block spacing are equal.

8 0.315 5 x 10 0.197 x 0.394 32 White MG-CPM-04 41390 1SNB041390R0510 41

Yellow MG-CPM-04 41340 1SNB041340R0510 41

Strip markers 6 x 10 0.236 x 0.394 48 White MG-CPM-04 41391 1SNB041391R0610 45
6 0.236

Support plate MG2-QTB 991011 1SNB991011R0000
Included in the MG3 Kit

MG-CPM-05

Individual markers

5 0.197 5 x 10 0.197 x 0.394 56 White MG-CPM-05 41490 1SNB041490R0510 51
MG2-WTB 991004 1SNB991004R0000
Support plate
Purchased separately

MG-CPM-12 White MG-CPM-12 46390 1SNB046390R4209 112
MG2-WTB 991004 1SNB991004R0000
Flexible pitch strip markers
5 ... 6 0.197 ... 0.236 4.2 x 9 0.165 x 0.354 56

Support plate
Purchased separately

Refer to selection page for information on strip markers.

1SNC160165S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
