MG-CPMF terminal block markers
Blank strip labels for SNK, SNA and Solution series

Description
–– To be directly used on terminal block assembly,
–– Available in precut or self-adhesive versions to fit all applications.

1SNC160132F0014 Main technical data Flammability Temperature range
V0 -30°C to +80°C -22°F to +176°F
Material
Rigid PVC

MG-CPMF Ordering details Nb. of Color Type Order code SW 3
markers code
Dimensions per card Pkg Weight
marker (1 marker) g
mm in
1000 0.30
SNA and Solution series terminal block markers 600 1.00
500 1.20
MG-CPMF
400 2.60
Strip labels for all terminal blocks from the SNA and Solution series 400 2.60

5.2 x 105 0.205 x 4.134 20 White MG-CPMF 43094 1SNB043094R0052 551 100 6.23
1SNB043091R0076 552
7.6 x 105 0.299 x 4.134 12 White MG-CPMF 43091 1SNB043090R0010 530

10 x 105 0.394 x 4.134 10 White MG-CPMF 43090 1SNB043196R0012 330
1SNB043146R0012 330
SNK series terminal block markers
1SNB046990R0010 530
MG-CPMFA

Self-adhesive strip labels for all terminal blocks from the SNK series

12 x 105 0.472 x 4.134 8 White MG-CPMFA 43196

Yellow MG-CPMFA 43146

Component and equipment markers

MG-CPMFA

Self-adhesive strip labels for various applications

10 x 105 0.394 x 4.134 10 White MG-CPMFA 46990

Marking system accessories MG2-PLT 991002 1SNB991002R0000 1 148.50

MG2-PLT
Support plate
Included in the MG3 Kit

Mounting instruction

1SNC160166S0201 - Rev. A

All the technical data for UL/CSA standard and dimensions in inches are in italic.

ABB Solution series - Markers and marking systems | 47
