MG-TAA component and equipment markers
Self-adhesive precut blank labels

Description

–– To be used for external marking of components and equipment,
–– Direct application on suitable surfaces (self-adhesive),
–– Made of rigid PVC.

3 1SNC160139F0014 Main technical data Flammability Temperature range
V0 -30°C to +80°C -22°F to +176°F
MG-TAA Material
Rigid PVC

Ordering details Nb. of Color Type Order code SW Pkg Weight
markers code
Dimensions per card MG-TAA 49196 marker (1 marker) g
MG-TAA 49493 1500 0.30
mm in 60 White MG-TAA 49498 1SNB049196R0720 179 1800 0.30
72 White MG-TAA 49448 1SNB049493R0817 194 825 0.55
7 x 20 0.276 x 0.787 33 White MG-TAA 49397N 1SNB049498R8530 720 825 0.55
8 x 17 0.315 x 0.669 Yellow MG-TAA 49190N 1SNB049448R8530 720 1925 0.30
8.5 x 30 0.335 x 1.181 White MG-TAA 49191N 1SNB049397R0915 961 1375 0.40
White MG-TAA 49193N 1SNB049190N0920 962 825 0.60
9 x 15 0.354 x 0.591 77 White MG-TAA 49143N 1SNB049191R0935 964 700 0.70
9 x 20 0.354 x 0.787 55 White MG-TAA 49298 1SNB049193R1527 966 700 0.70
9 x 35 0.354 x 1.378 33 Yellow MG-TAA 49194N 1SNB049143R1527 966 300 1.20
15 x 27 0.591 x 1.063 28 White MG-TAA 49144N 1SNB049298R1544 854 350 1.40
White MG-TAA 49195N 1SNB049194R1549 967 350 1.50
15 x 44 0.591 x 1.732 12 Yellow MG-TAA 49145N 1SNB049144R1549 967 175 2.80
15 x 49 0.591 x 1.929 14 White MG-TAA 49198 1SNB049195R1567 968 175 2.80
Yellow MG-TAA 49148 1SNB049145R1567 968 450 0.91
15 x 67 0.591 x 2.638 7 White 1SNB049198R1735 711 450 0.91
Yellow 1SNB049148R1735 711
17 x 35 0.669 x 1.378 18 1 148.50

Marking system accessories MG2-PLT 991002 1SNB991002R0000

MG2-PLT
Support plate
Included in the MG3 Kit

Mounting instruction

AF09 contactor with MG-TAA 49196 marker

Compatible holders

LH LH-R1 PEB 1SNC160179S0201 - Rev. B
(only for MG-TAA 49498 and 49448) (only for MG-TAA 49198 and 49148) (only for MG-TAA 49198 and 49148)

All the technical data for UL/CSA standard and dimensions in inches are in italic.
