PM, PM-ET and PM-AC transparent marker holders
For MG-TPM markers

1SNC160251F0014 Description
–– Compatible with MG-TPM markers,
–– Made of plasticised PVC.

Main technical data

Material Flammability Temperature range

PM PVC V0 -40°C to +90°C -40°F to +194°F

Ordering details Wire Holder Color Type Order code 3
section length
Wire ext. diameter mm² mm in Pkg Weight
pce (1 pce) g
mm in

For cable mounting

PM

Profiled transparent holder to allow each type to accommodate a range of cable sizes

2 ... 3.7 0.079 ... 0.146 0.5 ... 2.5 10 0.394 Transparent PM-01 50100 1SNB050100R0000 6000 0.20
2000 0.20
Transparent PM-01 50102 1SNB050102R0001 2000 0.10
5000 0.20
Transparent PM-01 50102-HF 1SNB050102R0002 4000 0.20
1000 0.20
PM-01 12 0.472 Transparent PM-01 50110 1SNB050110R0000 4000 0.30
1000 0.30
PM-ET 15 0.591 Transparent PM-01 50120 1SNB050120R0000 4000 0.30
PM-AC 1000 0.30
Transparent PM-01 50122 1SNB050122R0000 3000 0.35
1000 0.35
3.5 ... 4.3 0.138 ... 0.169 2.5 ... 4 10 0.394 Transparent PM-02 50200 1SNB050200R0000 3000 0.30
1000 0.30
Transparent PM-02 50202 1SNB050202R0000 2000 0.40
500 0.40
12 0.472 Transparent PM-02 50210 1SNB050210R0000 2000 0.45
500 0.45
Transparent PM-02 50212 1SNB050212R0000 2000 0.45
500 0.45
15 0.591 Transparent PM-02 50220 1SNB050220R0000 1000 0.50
500 0.50
Transparent PM-02 50222 1SNB050222R0000 1000 0.60
500 0.60
4 ... 6.3 0.157 ... 0.248 4 ... 10 10 0.394 Transparent PM-03 50300 1SNB050300R0000 500 0.70
500 0.80
Transparent PM-03 50302 1SNB050302R0000 250 1.10
500 1.30
12 0.472 Transparent PM-03 50310 1SNB050310R0000 250 1.40
250 2.70
Transparent PM-03 50312 1SNB050312R0000
0.40
15 0.591 Transparent PM-03 50320 1SNB050320R0000 0.50

Transparent PM-03 50322 1SNB050322R0000 0.20
0.20
6 ... 10 0.236 ... 0.394 10 ... 25 10 0.394 Transparent PM-04 50400 1SNB050400R0000 0.30

Transparent PM-04 50402 1SNB050402R0000

12 0.472 Transparent PM-04 50410 1SNB050410R0000

Transparent PM-04 50411 1SNB050411R0000

15 0.591 Transparent PM-04 50420 1SNB050420R0000

Transparent PM-04 50421 1SNB050421R0000

9 ... 15 0.354 ... 0.591 25 ... 70 10 0.394 Transparent PM-05 50500 1SNB050500R0000

12 0.472 Transparent PM-05 50510 1SNB050510R0000

15 0.591 Transparent PM-05 50521 1SNB050521R0000

14 ... 26 0.551 ... 1.024 70 ... 240 10 0.394 Transparent PM-06 50600 1SNB050600R0000

12 0.472 Transparent PM-06 50610 1SNB050610R0000

15 0.591 Transparent PM-06 50620 1SNB050620R0000

PM-ET

Tie-on transparent holder for longitudinal mounting on cables, hoses, tubes and conduit (tie width max 6 mm 0.236 in)

12 0.472 Transparent PM-ET 53010 1SNB053010R0000 2000

15 0.591 Transparent PM-ET 53020 1SNB053020R0000 2000

For surface mounting 1SNB051000R0000 5000
1SNB051010R0000 4000
PM-AC 1SNB051020R0000 4000
Self-adhesive transparent holder to be used over all plane surfaces

10 0.394 Transparent PM-AC 51000N
12 0.472 Transparent PM-AC 51010N
15 0.591 Transparent PM-AC 51020N

Use holders only with designated cable marker of the same or a shorter length.

1SNC160172S0201 - Rev. A

All the technical data for UL/CSA standard and dimensions in inches are in italic.
