MG-TDM wire and cable markers
Slide-on cable blank markers

Description

–– To be directly printed and slided onto the wire,
–– Partially printed marker cards may be re-used to avoid wastage,
–– Made of rigid polycarbonate.

3 1SNC160117F0014 Main technical data Flammability Temperature range
V0 -40°C to +140°C -40°F to +284°F
MG-TDM-01 Material
Polycarbonate

Ordering details Nb. of Color Type Order code SW Pkg Weight
markers code marker (1 marker) g
Dimensions per card
1320 0.30
mm in 1320 0.30
1 126.00
Cable Ø 1.6-3.25 mm 0.06-0.12 in Section 0.5-1.5 mm²
800 0.30
MG-TDM-01 Length 12 mm 0.472 in 800 0.30
1 116.00
4 x 12 0.157 x 0.472 66 White MG-TDM-01 40190 1SNB040190R0412 121
Yellow MG-TDM-01 40140 1SNB040140R0412 121 1056 0.30
1056 0.30
Support plate MG2-PTD 991007 1SNB991007R0000 1 126.00
Purchased separately
640 0.40
MG-TDM-01 Length 16 mm 0.630 in 640 0.40
1 116.00
4 x 16 0.157 x 0.630 40 White MG-TDM-01 40191 1SNB040191R0416 123
Yellow MG-TDM-01 40141 1SNB040141R0416 123

Support plate MG2-PTM 991010 1SNB991010R0000
Purchased separately

Cable Ø 2-4.4 mm 0.07-0.17 in Section 1-6 mm²

MG-TDM-02 Length 12 mm 0.472 in

4 x 12 0.157 x 0.472 66 White MG-TDM-02 40290 1SNB040290R0412 122
Yellow MG-TDM-02 40240 1SNB040240R0412 122

Support plate MG2-PTD 991007 1SNB991007R0000
Purchased separately
1SNB040291R0416 124
MG-TDM-02 Length 16 mm 0.630 in 1SNB040241R0416 124

4 x 16 0.157 x 0.630 40 White MG-TDM-02 40291 1SNB991010R0000
Yellow MG-TDM-02 40241

Support plate MG2-PTM 991010
Purchased separately

Mounting instruction

1SNC160168S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
