MG-TPM wire and cable markers
Slide-in precut blank labels

Description

–– To be slided into PM holder,
–– For cable up to 240 mm²,
–– PM holders can be directly inserted on the markers without removing them from the stems,
–– Made of rigid ABS.

1SNC160116F0014 Main technical data

3 Material Flammability Temperature range
-30°C to +80°C -22°F to +176°F
MG-TPM Acrylonitrile Butadienne Styrene (ABS) V0

Ordering details Nb. of Color Type Order code SW Pkg Weight
markers code
Dimensions per card MG-TPM 40090 marker (1 marker) g
MG-TPM 40091
mm in MG-TPM 40092 2250 0.30
2250 0.30
14B3V1 MG-TPM 2250

4 x 10 0.157 x 0.394 45 White 1SNB040090R0410 1
White 1SNB040091R0412 2
4 x 12 0.157 x 0.472 White 1SNB040092R0415 3

4 x 15 0.157 x 0.591

Marking system accessories MG2-PWC 991000 1SNB991000R0000 1 148.50

MG2-PWC
Support plate
Included in the MG3 Kit

Compatible holders PM-AC 1SNC160171S0201

PM PM-ET
All the technical data for UL/CSA standard and dimensions in inches are in italic.
