MG-TPMF wire and cable markers
Slide-in precut blank labels

Description

–– To be slided into PMF holder,
–– For wire and cable up to 70 mm²,
–– Made of rigid PVC.

3 1SNC160115F0014 Main technical data Flammability Temperature range
V0 -30°C to +80°C -22°F to +176°F
MG-TPMF Material
Rigid PVC

Ordering details Nb. of Color Type Order code SW Pkg Weight
markers code
Dimensions per card MG-TPMF 42090B marker (1 marker) g
MG-TPMF 42091B
mm in MG-TPMF 42092B 5600 0.10
4000 0.10
13Q2L1 MG-TPMF 4000 0.10

4 x 10 0.157 x 0.394 112 White 1SNB042090R0410 502
80 White 1SNB042091R0412 505
4 x 12 0.157 x 0.472 White 1SNB042092R0415 503

4 x 15 0.157 x 0.591

Marking system accessories MG2-PLT 991002 1SNB991002R0000 1 148.50

MG2-PLT
Support plate
Included in the MG3 Kit

Compatible holders

PMF PMF-ET PMF-AC 1SNC160173S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
