MG2-TDMO wire and cable markers
Clip-on cable blank markers
Description
–– To be directly printed and clip onto the wire,
–– Partially printed marker cards may be re-used to avoid wastage,
–– Made of rigid polycarbonate.
1SNC160118F0014 Main technical data Flammability Temperature range 3
V0 -40°C to +140°C -40°F to +284°F
Material Pkg Weight
Polycarbonate marker (1 marker) g
MG2-TDMO-01 Ordering details Nb. of Color Type Order code SW 880 0.30
markers code 800 0.30
Dimensions per card 880 0.30
800 0.30
mm in
640 0.40
Cable Ø 2-2.9 mm 0.07-0.11 in Section 0.5-1.5 mm² 640 0.40
640 0.40
M G 2-T D M O - 0 1 640 0.40
4 x 12 0.157 x 0.472 40 White MG2-TDMO-01 40390 1SNB040390R0412 125 560 0.40
Yellow MG2-TDMO-01 40340 1SNB040340R0412 125 560 0.40
4 x 16 0.157 x 0.630 White MG2-TDMO-01 40391 1SNB040391R0416 128 560 0.40
Yellow MG2-TDMO-01 40341 1SNB040341R0416 128 560 0.40
Cable Ø 2.9-3.5 mm 0.11-0.14 in Section 1.5-2.5 mm²
M G 2-T D M O - 0 2
4 x 12 0.157 x 0.472 40 White MG2-TDMO-02 40490 1SNB040490R0412 126
Yellow MG2-TDMO-02 40440 1SNB040440R0412 126
4 x 16 0.157 x 0.630 White MG2-TDMO-02 40491 1SNB040491R0416 129
Yellow MG2-TDMO-02 40441 1SNB040441R0416 129
Cable Ø 4-4.6 mm 0.16-0.18 in Section 4-6 mm²
M G 2-T D M O - 0 3
4 x 12 0.157 x 0.472 40 White MG2-TDMO-03 40590 1SNB040590R0412 127
Yellow MG2-TDMO-03 40540 1SNB040540R0412 127
4 x 16 0.157 x 0.630 White MG2-TDMO-03 40591 1SNB040591R0416 130
Yellow MG2-TDMO-03 40541 1SNB040541R0416 130
Marking system accessories MG2-PTM 991010 1SNB991010R0000 1 116.00
MG2-PTM
Support plate
Purchased separately
Mounting instruction
Compatible holders 1SNC160169S0201 - Rev. A
UMH
All the technical data for UL/CSA standard and dimensions in inches are in italic.
