UMH wire and cable marker holders
Universal wire marker holders
1SNK160090F0014 Description
–– Compatible with most of the wire markers available on the market (wire markers not supplied with UMH),
–– Quickly fit to any SNK terminal blocks and accessories: strip mounting of 10 parts for 5.2 mm 0.205 in
spacing, unitary mounting for other spacings
UMH Main technical data Flammability Temperature range
V0 -55°C to +110°C -67°F to +230°F
3 Material
Polyamide
Ordering details Nb. of Color Type Order code Pkg Weight
markers Grey UMH 1SNK900611R0000
Dimensions per card pce (1 pce) g
10 0.20
mm in 10
14.5 x 6 0.571 x 0.236
Mounting instruction
Install the UMH on the terminal blocks (strip mounting) and slide on the wire
markers.
1SNC160186S0201
All the technical data for UL/CSA standard and dimensions in inches are in italic.
