CP-D range
Ordering details

2CDC 271 024 F0007 Description 3

The CP-D range of modular power supply units in MDRC design (modular DIN rail compo-
nents) is ideally suited for installation in distribution panels. This range offers devices with
output voltages of 12 V DC and 24 V DC at output currents of 0.42 A to 4.2 A. Thanks to a
high thermal efficiency corresponding to low power and heat dissipation, the devices can be
operated without forced cooling. All devices feature the U/I output characteristic (fold forward
behaviour). All power supply units in the CP-D range are approved according to all relevant
international standards.

Ordering details Rated Type Order code Price Weight
output voltage / 1 pce (1 pce)
CP-D 12/0.83, CP-D 24/0.42 Input voltage range current 1SVR427041R1000 kg (lb)
CP-D 12/2.1, CP-D 24/1.3 1SVR427043R1200
90-264 V AC/ 120-375 V DC 12 V DC / 0.83 A CP-D 12/0.83 1SVR427041R0000 0.06
90-264 V AC/ 120-375 V DC 1SVR427043R0100 (0.13)
90-264 V AC/ 120-375 V DC 1SVR427044R0200
90-264 V AC/ 120-375 V DC 12 V DC / 2.1 A CP-D 12/2.1 1SVR427045R0400 0.19
90-264 V AC/ 120-375 V DC (0.41)
90-264 V AC/ 120-375 V DC
24 V DC / 0.42 A CP-D 24/0.42 0.06
(0.13)

24 V DC / 1.3 A CP-D 24/1.3 0.19
(0.41)

2CDC 271 025 F0007 24 V DC / 2.5 A CP-D 24/2.5 0.25
(0.56)

24 V DC / 4.2 A CP-D 24/4.2 0.32
(0.71)

2CDC 271 028 F0007

CP-D 24/2.5

2CDC 110 004 C0210 | Catalog Electronic Products and Relays 2015 | ABB 3/10
