CP-D range
Technical data

Data at Ta = 25 °C, Uin = 230 V AC and rated values, unless otherwise indicated

Type CP-D 12/0.83 CP-D 12/2.1
0.2-2.5 mm2 (24-14 AWG)
Electrical connection - Input circuit / Output circuit 0.2-2.5 mm2 (24-12 AWG)
7 mm (0.28 in)
Wire size fine-strand with wire end ferrule 0.2-1.5 mm2 (24-16 AWG) 0.7 Nm (6 lb.in)

Stripping length rigid 0.2-2.5 mm2 (26-12 AWG) Level 4 (4 kV / 15 kV)
4-5 mm (0.16-0.2 in)

Tightening torque 0.6 Nm (5 lb.in)

Environmental data 3
Ambient temperature range
operation -40…+70 °C
Damp heat (cyclic) (IEC/EN 60068-2-30) rated load -40…+60 °C
Vibration (sinusoidal) (IEC/EN 60068-2-6)
Shock (half-sine) (IEC/EN 60068-2-27) storage -40…+85 °C
4 x 24 cycles, 40 °C, 95 % RH
50 m/s2, 10 Hz - 2 kHz
40 m/s2, 22 ms

Isolation data input circuit / output circuit 3 kV AC
Rated insulation voltage Ui 2
Pollution degree ll

Overvoltage category (UL/IEC/EN 60950-1)

Standards EN 61204
Product standard 2006/95/EC
Low Voltage Directive 2004/108/EC
EMC Direcitve UL 508, UL 60950-1, EN 60950-1
Electrical safety SELV (EN 60950-1)
Protective low voltage

Electromagnetic compatibility EN 61000-6-2
Interference immunity to

electrostatic discharge IEC/EN 61000-4-2 Level 4 (4 kV / 8 kV)

radiated, radio-frequency, electromagnetic field IEC/EN 61000-4-3 Level 3 (10 V/m)

electrical fast transient/burst IEC/EN 61000-4-4 Level 4 (4 kV)

surge IEC/EN 61000-4-5 Level 3 (2 kV L-L)

conducted disturbances, induced by radio- IEC/EN 61000-4-6 Level 3 (10 V)
frequency fields EN 61000-6-3
Interference emission

high-frequency radiated IEC/CISPR 22, EN 55022 Class B

high-frequency conducted IEC/CISPR 22, EN 55022 Class B
