CP-D range
Technical data

Data at Ta = 25 °C, Uin = 230 V AC and rated values, unless otherwise indicated

Type CP-D 12/0.83 CP-D 12/2.1
Input circuit - supply circuit L, N
Rated input voltage Uin 100-240 V AC
Input voltage range 90-264 V AC / 120-375 V DC 502 mA / 31.14 W
Frequency range AC 47-63 Hz 277 mA / 31.2 W
at 110 V AC 200 mA / 12.68 W 50 A (max. 3 ms)
3 Typical input current / at 230 V AC 128.3 mA / 13.01 W 2 A slow-acting / 250 V AC
typical power consumption at 230 V AC 30 A (max. 3 ms)
min. 30 ms
Inrush current limiting 1 A slow-acting / 250 V AC
Power failure buffering time no
Internal input fuse
Power factor correction (PFC)

Indication of operational states DC ON: green LED V: output voltage applied
Output voltage DC LOW: red LED V: output voltage too low

Output circuit +, - ++, --
Rated output voltage
12 V DC 12-14 V DC
25 W
Tolerance of the output voltage ±1 % 2.1 A

Adjustment range of the output voltage -

Rated output power 10 W

Rated output current Ir Ta ͨ 60 °C 0.83 A

Derating of the output current 60 °C < Ta ͨ 70 °C 2.5 %/°C

Maximum load change statical max. 1 %

deviation change of output voltage within the input voltage range max. 1 %
with

Control time < 1 ms

Starting time after applying the supply at Ir 1000 ms
voltage at rated load typ. 1 ms
Rise time

Residual ripple and switching peaks BW = 20 MHz 50 mV

Parallel connection yes, using CP-D RU

Series connection yes, to increase voltage

Resistance to reverse feed 18 V / 1 s

Output circuit - No-load, overload and short-circuit behaviour U/I characteristic curve
Characteristic curve of output
Short-circuit protection continuous short-circuit stability
Short-circuit behaviour
Current limiting at short circuit continuation with output power limiting
Overload protection
Overvoltage protection typ. 1.4 A typ. 5.9 A
No-load protection
Starting of capacitive loads output power limiting

15-16.5 V DC

continuous no-load stability

unlimited

General data typ. 78 % typ. 82 %
Efficiency
Duty time 100 %
Dimensions (W x H x D)
18 x 91 x 57.5 mm 53 x 91 x 57.5 mm
Weight (0.71 x 3.58 x 2.26 in) (2.09 x 3.58 x 2.26 in)
Material of housing 0.066 kg (0.13 lb) 0.196 kg (0.41 lb)
Mounting
Mounting position plastic
Minimum distance to other units
Degree of protection DIN rail (IEC/EN 60715), snap-on mounting without any tool
Protection class
horizontal

horizontal / vertical 25 mm / 25 mm (0.98 in / 0.98 in)

housing / terminals IP20 / IP20

II
