Interface relays R600 range
Ordering details

Ordering details - 1 c/o (SPDT) contact: 250 V, 10 mA - 6 A (high level), width 6 mm

Rated control Particularities and Type Order code Price Pkg Weight
qty (1 pce)
supply connection type
kg (lb)
voltage

5 V DC A1-A2 polarized RB121-5VDC 1SNA645034R2300

12 V DC A1-A2 polarized RB121-12VDC 1SNA645035R2400

12 V DC RB121-12VDC 1SNA645073R0000

24 V DC RB121-24VDC 1SNA645071R0000

24 V AC/DC RB121A-24VAC/DC 1SNA645001R0300

48-60 V AC/DC RB121A-48-60VAC/DC 1SNA645002R0400

2CDC 291 013 S0013 115 V AC/DC RB121A-115VAC/DC 1SNA645003R0500

230 V AC/DC A1-A2 polarized RB121A-230VAC/DC 1SNA645004R0400 10 0.02
5 V DC RBR121-5VDC 1SNA645534R2500 (0.044)

12 V DC A1-A2 polarized RBR121-12VDC 1SNA645535R2600

12 V DC RBR121-12VDC 1SNA645573R0000 5

R600 - 12 mm 24 V DC RBR121-24VDC 1SNA645571R0000

screw terminals 24 V AC/DC RBR121A-24VAC/DC 1SNA645501R0500
spring terminals
48-60 V AC/DC RBR121A-48-60VUC 1SNA645502R0600

115 V AC/DC RBR121A-115VAC/DC 1SNA645503R0700

230 V AC/DC RBR121A-230VAC/DC 1SNA645504R0000

Ordering details - 1 c/o (SPDT) contact: 250 V, 10 mA - 6 A (high level), width 12 mm

Rated control Particularities and Type Order code Price Pkg Weight
supply voltage connection type RB121A-60-230VUC qty (1 pce)

60-230 V AC/DC kg (lb)

1SNA645020R0100

115 V AC/DC Leakage current RB121AR-115VAC/DC 1SNA645046R0700 0.04
230 V AC/DC protection, input side RB121AR-230VAC/DC 1SNA645011R2400 (0.088)
RBR121A-60-230VUC 1SNA645520R0300
60-230 V AC/DC Leakage current RBR121AR-115VAC/DC 1SNA645546R0100
115 V AC/DC protection, input side RBR121AR-230VAC/DC 1SNA645511R2600

230 V AC/DC

Ordering details - 2 c/o (SPDT) contacts: 250 V, 1 mA - 8 A (low level), width 12 mm

Rated control Connection type Type Order code Price Pkg Weight
supply voltage qty (1 pce)
RB122A-24VAC/DC
24 V AC/DC RB122A-48-60VAC/DC kg (lb)
48-60 V AC/DC RB122A-115VAC/DC
115 V AC/DC RB122A-230VAC/DC 1SNA645012R2500 5 0.04
230 V AC/DC RBR122A-24VAC/DC 1SNA645040R1500 (0.088)
24 V AC/DC RBR122A-48-60VUC 1SNA645041R0200
48-60 V AC/DC RBR122A-115VAC/DC 1SNA645013R2600
115 V AC/DC RBR122A-230VAC/DC 1SNA645512R2700
230 V AC/DC 1SNA645540R1700
1SNA645541R0400
1SNA645513R2000

Ordering details - Accessories

Description Type Order code Price Pkg Weight
qty (1 pce)

kg (lb)

BJ... SC612 24 V AC/DC BJ 612-10 1SNA290488R0100 0.05
48-60 V AC/DC BJ 612-20 1SNA206754R0000 (0.11)
230 V AC/DC SC 612 1SNA290474R0200
10 0.01
(0.022)

0.05
(0.11)
