ABB ABILIT Y TM AUTOMATION BUILDER – INTEGR ATED ENGINEERING SUITE 65

—
ABB Ability Automation Builder
TM
Library features

02

PS552-MC-E PS565-BACnet-ASC PS573-PCO
Motion control library BACNet communication library Process control objects library
Library enabling fast and stan dardized This library enables AC500 PLCs to connect Facilitates the use of AC500 as controller
engineering according to PLCopen standard OEM or infrastructure applications to BMS in DCS solutions by providing function blocks
when using ABB's AC500 PLC for motion (Building Management Systems) or other for easy integration into the process
control, especially together with ABB's motion controllers. visualization.
control Drives.
The PS565-BACnet-ASC library enables AC500 Twelve function blocks are available which
Covers different motion control options for to serve as BACnet server device, complying cover the following functionalities:
single and multi-axes motion control with the B-ASC Device Profile and interfacing • Digital and analog setpoints
applications: control requirements, and acting as hardwired • Analog measurement with threshold alarm
• Drive-Based and PLC-Based motion or Modbus-to-BACnet gateway. functions
• In PLC based interpolation, the position • Valve control
control loop could be closed in the PLC or It supports BACnet IP (Ethernet) and BACnet • Motor control with or without variable
drive (with synchronized network) MS/TP (serial) networks. The scalable AC500 speed drives
• Single axis, multi-axes and coordinated platform is compatible with the BACnet library • Proportional integral controller
motion starting from eCo PM5x6 with larger memory
• Defined Jerk limitation by polynomial (~ 300 objects) up to PM595 (more than 5000 The function blocks have an internal interface
inter polation objects). to the DCS system. Status and control are
• Spline interpolation or polynomial exchanged with the DCS system via OPC DA.
inter polation for cam curves, position The very transparent, object-oriented publish For ABB Ability System 800xA an optional
TM
velocity or acceleration profiles available and subscribe approach of BACnet allows object library is available which contains
• Possible to switch over between different efficient and well-documented engineering symbols and faceplates that match the
movements and cam curves on the fly and collaboration of many different parties in function blocks.
• latch functionality by utilizing fast drive large infrastructure projects.
inputs for ACS350, ACS800, ACSM1
• Drive based motion: commands from PLC, Highlights
drives perform inter polation and control loop • Easy-to-use BACnet communication directly
• Supports the new Pulse Train Output module in the CPU
FM562. • No coupler or gateways required
• Cost-efficient particularly for OEMs and
PLCopen functions: projects
• Administrative Function Blocks • Interfacing other non-BACnet devices to
• Single axis Function Blocks BMS.
• Multi-axes Function Blocks
• Homing Function Blocks BACnet for AC500 is BTL approved and
• Coordinated Motion Function Blocks certified.
• Additional ABB specific Function Blocks for
further simplification.
License Package (Software is part of Automation Builder) (No license required)
All AC500 V2 CPUs (options and no. of blocks/ All AC500 V2 CPUs, starting from PM5x6 All AC500 V2 CPUs have an onboard Ethernet
functions and performance will depend on (~300 objects) up to PM595 (>5000 objects) interface (number of function blocks and
CPU size and memory). performance will depend on the CPU size and
memory).
