66 MAIN CATALOG PLC AUTOMATION

—
ABB Ability Automation Builder
TM
Runtime license features

02

PS5601-HA-MTCP PS5602-61850 PS5604-KNX
High availability library using Ethernet IEC 61850 MMS server and KNX IP communication
(Modbus TCP) GOOSE communication
Runtime license per CPU to download library This runtime license enables the AC500 V3 PLC This runtime license enables the AC500 V3 PLC
into the CPU. to connect to substation type equipment to connect to KNX IP.
(IEDs) or act as IED.
Same philosophy as proven serial/CS31 based The protocol and configuration options are part
library. The protocol library and configuration tool are of Automation Builder and FW. The runtime
part of Automation Builder. The runtime license is needed for download.
Enables hot-standby redundancy and bumpless license is needed for download.
transfer with standard AC500 CPUs. Support of
Supports 3 redundancy levels: 61850 server edition 1 allows: • Up to 1000 group objects
• CPU • sending MMS messages to ensure a safe • Programming the physical address via ETS
• I/O communication data communication – no real time support • Downloading the KNX group address linking
• SCADA communication • publishing and subscribing to GOOSE via ETS
messages for high priority peer-to-peer data
Library package containing libraries based on exchange between different servers to Highlights
Modbus TCP for field communication and using ensure a data transmission with minimal • Easy to use KNX communication directly in CPU
CI52x communication interface modules as delay due to tight ETS5 and Automation Builder
I/O clusters with redundant connection. • up to 5 client connections per server integration via DCA
• up to 50 entries per dataset • No coupler or gateways needed
Ethernet redundancy based on externally • up to 20 datasets • Cost-efficient especially for OEMs and projects
managed switches: Ethernet network can be • Enables holistic building automation solutions.
independent of the redundancy mechanism Automation Builder used as IED configuration
used. tool
• Daisy chain in ring configuration of CI52x • Import / export of SCL files formats
with MRP as redundancy protocol • ICD – IED capability description file
• Fast reaction and switchover nearly • SCD – substation configuration description
independent of the number of clusters file
• Possibility of integrating other devices e.g. • CID – configured IED description file
ABB drives into the redundancy scheme.
Basic display options
Scalable redundancy, where CPUs can also be
placed far away from each other (…kilometers Highlights
if fiber-optic networks are used). • Wide set of Logical Nodes provided
• Further Logical Nodes can be defined
Includes the AC500 Bulk Data Manager as a tool • Implementation can be programmed freely
for efficient configuration and cluster in IEC 61131.
engineering.
• Configuration and export of projects, The IEC 61850 protocol of the AC500 PLC is
clusters, modules/parameters, signal names, TÜV certified.
visualization (“code generation”)
Application examples for fast engineering and
startup.
Runtime license (Software is part of Automation Builder)

All AC500 V2 and V3 CPUs All AC500 V3 CPUs All AC500 V3 CPUs
