165LTTM5TM5 ring lug terminal blocks
Feed-through - 16 mm 0.630 in spacing

Description
16 mm²
– Two stud terminal block for ring lug connection,
– Profile aligned with disconnect terminal blocks type 165ETTM5TM5.
Ordering details
Description Color Type Part Number Pkg Weight
pce (1 pce) g
1SNC168034F0014 and partition
WIth 2 studs M5 x 16
Feed-through
25
165LTTM5TM5
1SNA216110R2200
40.00
Grey
Main technical data
IEC UL CSA Mounting instructions G32, TH 35-7.5,
Rail
Lugs Rigid: Solid/Stranded 16 mm² 6 AWG TH 35-15
Flexible with JOTVMBUFE GFSSVMF 16 mm² Lugs Wrench
165LTTM5TM5 Gauge Tool H8 mm
Rated current 76 A 65 A 0.310 in
Rated cross section 16 mm² 6 AWG Torque 2 - 4 N.m
Rated voltage 800 V 600 V 17.7 - 35.4 lb.in
74 2.91" Impulse withstand voltage 8 kV Wire stripping
Protection NEMA length
56.5 2.23" The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
54 2.13" RoHS USR EAC
49 1.92"
37 1.46"
42 1.65" 5

16 mm 0.630 in spacing

Accessories
Description Color Type Part Number Pkg Weight
pce (1 pce) g
1 2
1 End stops 10 mm 0.079 in Dark grey BAM4 1SNK900001R0000 50 14.00
5.2 mm 0.205 in BAZ1 1SNK900002R0000 50 5.30
2 End sections 2 mm 0.079 in Grey FEET80 1SNA216114R1200 10 7.20
3 Test sockets DIA 4 mm 0.157 in AL4-M3-R1 1SNA206722R0200 50 1.62
3 4 4 Protecting covers Length 2 m 78 in CPE80 1SNA280093R2600 1 103.00
5 Terminal block markers Blank card REH3 1SNA163155R2600 1 20.00
Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.
5

1SNC168007S0201 - Rev. B

Technical data valid for copper conductors only.
