ZS10-S-R2 screw clamp terminal blocks
         Disconnect with lever - 8 mm 0.315 in spacing



                                    Description
                        10 mm²
                                    Simplify the disconnect operations for the disconnect terminal blocks installed next to fuse terminal blocks ZS10-SF:
                        6 AWG          – With the same profile as ZS10-SF, the ZS10-S-R2 disconnect lever is easily operated by hand and the wiring
                                      of the alternated disconnect and fuse circuits is easier.

                                    Ordering details
                                    Description                   Color     Type      Part Number        Pkg  Weight
                                                                                                         qty  (1 pce) g
                            1SNK161070F0014  Main technical data                       Mounting instructions
                                                                                      1SNK508417R0000
                                                                                                               35.90
                                              Profile aligned with ZS10-SF
                                    Disconnect
                                                                                                         50
                                                                   Grey, orange
                                                                            ZS10-S-R2
                                                                  IEC
                                                                                                         TH 35-7.5,
                                                                                       Rail
                                    Connecting capacity
                                                                            UL - CSA
                                                                                                         TH 35-15
                                    1 conductor   Rigid: Solid/Stranded  0.5 ... 10 mm²  24 ... 6 AWG  Wire stripping   13 mm
                                    per clamp  Flexible without ferrule  0.5 ... 10 mm²  length          0.512 in
                                             Flexible with non insulated ferrule  0.5 ... 10 mm²  24 ... 8 AWG
         ZS10-S-R2                           Flexible with insulated ferrule  0.5 ... 6 mm²  24 ... 10 AWG
                                             Gauge                A5-B5
                                    2 conductors   Rigid: Solid/Stranded  0.5 ... 4 mm²  20 ... 12 AWG  Tool  Flat screwdriver
                                    per clamp  Flexible without ferrule  0.5 ... 4 mm²                   Ø 4 mm
               74.3  2.93"                   Flexible with twin ferrule  0.5 ... 4 mm²  20 ... 12 AWG    Ø 0.157 in
                                    Rated current / Rated cross section  10 A / 4 mm²  22 A / 25 AWG
                                    Maximum current / Maximum cross section  25 A / 10 mm²
                                    Rated short-time withstand current (1s)  480 A     Torque            1.3 Nm ± 0.3
                                                                                                         11.5  lb.in ± 2.65
                                    Rated voltage
                            85.3  3.36"  77.8  3.06"  Impulse withstand voltage  6000 V  NEMA 1
                                                                            600 V
                                                                  630 V
                                                                  IP20
                                    Protection
                                    Recommendation for best usage: in horizontal assemblies, disconnect terminal blocks should be mounted
                                    with fixed foot on top (power side) so that the disconnect lever does not partially close through gravity.
                                    Furthermore, as specified per IEC 60947-7-1, disconnect terminal blocks are intended to be used for temporary
              26.7  1.05"
                                    disconnection at zero potential and at no load.
         8 mm 0.315 in spacing      The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
                                    All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
                                      CE   CB  RoHS  USR CNR  CSA  EAC                 BV  DNV
                                    Accessories
                                      Description                   Color   Type      Part Number        Pkg  Weight
         1           2
                                                                                                         qty  (1 pce) g
                                    1  End stops  10 mm   0.394 in   Dark grey  BAM4  1SNK900001R0000    50    14.00
                                    2  Jumper bars  2 poles   57 A (IEC)  Orange  JB8-2  1SNK908302R0000  50    2.70
                                                 3 poles   57 A (IEC)       JB8-3     1SNK908303R0000    50     4.10
         3           4                           4 poles   57 A (IEC)       JB8-4     1SNK908304R0000    50     5.60
                                                 5 poles   57 A (IEC)       JB8-5     1SNK908305R0000    40     7.00
                                                 10 poles   57 A (IEC)      JB8-10    1SNK908310R0000    20    14.20
                                    3  Test adapters  For test plugs DIA 2 mm 0.079 in  Dark grey  TP2  1SNK900203R0000  20  1.70
                                                 For test plugs DIA 4 mm 0.157 in  TP4  1SNK900205R0000  20     2.40
         5           6
                                    4  Test connectors  5.2 mm 0.205 in spacing  Dark grey  TC5  1SNK900200R0000  10  5.20  8
                                                 End module, 5.2 mm 0.205 in  TC5-R1  1SNK900201R0000    10     5.20
                                    5  Spacers   2.8 mm   0.110 in   Dark grey  ES-TC8  1SNK900104R0000  10     1.40
                                    6  Terminal block   Blank marker   White  MG-CPM 13 41791 1SNB041791R0612  1680  0.27
                                      markers    Blank card                 MC812     1SNK160000R0000    22    10.00
                                                                            MC812PA   1SNK169999R0000    20    14.00
                                                 Universal wire markers holder  Grey  UMH  1SNK900611R0000  10  0.20
                                    Complete list of accessories is indicated in the terminal block datasheet including end stops.
                                    Some accessories such as jumper bars may modify the terminal block's ratings: Complete information available in the accessories section of the catalog.



                                    Fuse screw clamp terminal blocks
                                    Description                   Color     Type      Part Number        Pkg  Weight  1SNK161055S0201
                                                                                                         qty  (1 pce) g
                                    Fuse         Closed block     Grey, dark grey  ZS10-SF  1SNK508418R0000  50  28.50



                                    Technical data valid for copper conductors only.
