K6 4-pole mini contactor relays – with flat pin connection
AC operated

Description
K6 4-pole mini-contactor relays are space optimized control products mainly used for control functions or
for small loads up to 4 A.
2CDC211034S0011 – flat pin connection for plug-in wiring and shake proven connection
These contactors are designed with:
– 4-poles with various contact combinations
– control circuit: AC operated
– low coil consumption (3.5 VA at pull-in and at holding)
3 K6-22Z-F – hum-free coil
– add-on auxiliary contact blocks for side mounting
– for rail and wall mounting
– add-on auxiliary contact blocks for side mounting
Ordering details
Rated control circuit voltage Type Order code Pkg Weight
U C qty (1 pce)
50 Hz 60 Hz
V AC V AC kg
K6 4-pole mini contactor relays
24 24 K6-22Z-F-01 GJH1211003R0221 10 0.170
42 42 K6-22Z-F-02 GJH1211003R0222 10 0.170
48 48 K6-22Z-F-03 GJH1211003R0223 10 0.170
110 ...127 110 ...127 K6-22Z-F-84 GJH1211003R8224 10 0.170
220 ... 240 220 ... 240 K6-22Z-F-80 GJH1211003R8220 10 0.170
380 ... 415 380 ... 415 K6-22Z-F-85 GJH1211003R8225 10 0.170
24 24 K6-31Z-F-01 GJH1211003R0311 10 0.170
42 42 K6-31Z-F-02 GJH1211003R0312 10 0.170
48 48 K6-31Z-F-03 GJH1211003R0313 10 0.170
110 ...127 110 ...127 K6-31Z-F-84 GJH1211003R8314 10 0.170
220 ... 240 220 ... 240 K6-31Z-F-80 GJH1211003R8310 10 0.170
380 ... 415 380 ... 415 K6-31Z-F-85 GJH1211003R8315 10 0.170
24 24 K6-40E-F-01 GJH1211003R0401 10 0.170
42 42 K6-40E-F-02 GJH1211003R0402 10 0.170
48 48 K6-40E-F-03 GJH1211003R0403 10 0.170
110 ...127 110 ...127 K6-40E-F-84 GJH1211003R8404 10 0.170
220 ... 240 220 ... 240 K6-40E-F-80 GJH1211003R8400 10 0.170
380 ... 415 380 ... 415 K6-40E-F-85 GJH1211003R8405 10 0.170

Other types on request

Main dimensions mm, inches
52.5 2.07" 46.7 1.84"
47.5 1.87" 43.7 1.72"

2.26" 1.78" 1.66"
57.5 45.2 42.2
2CDC212002F0011

4.5 0.18" 2CDC102040C0201
