Reversing starters protected by thermal overload relays

With AF contactors - open type version in kit form

Main dimensions mm, inches
180 7.09" 126 4.96"
8x
30 1.18" 60 2.36" 30 1.18" M4 8-32 UNC

100 3.94"

272 10.71"
5
45 1.77"

82.3 3.24"

4 x
M5 10-24 UNC

AF116, AF140, AF146 37 1.46"
+ BER140-4, VM19 50 1.97"
+ TF140 thermal overload relay

1SFC101158C0201
