AF09 ... AF38 2-stack 3-pole contactors

4 to 18.5 kW
AC / DC operated

Description
AF09 ... AF38 contactors are mainly used for controlling 3-phase motors and power circuits up to 690 V AC
and 220 V DC. These contactors are of the block type design with 3 main poles (1st stack):
– 2nd stack with permanently fixed auxiliary contact block. The built-in auxiliary contact elements are me-
chanically linked (side-marked symbol) and the N.C. auxiliary contacts are mirror contacts
1SBC101002V0014 – control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage
range (e.g. 100...250 V AC and DC), only 4 control voltage ranges covering 24...500 V 50/60 Hz and
20...500 V DC
- can manage large control voltage variations
AF09-30-22 - reduced panel energy consumption
- very distinct closing and opening.
– built-in surge suppression
– add-on auxiliary contact blocks for side mounting and a wide range of accessories.
Ordering details
5 IEC UL/CSA Rated control circuit Auxiliary Type Order code Weight
Rated operational 3-phase General voltage contacts (1)
power current motor use Uc min. … Uc max. fitted Pkg
θ ≤ 40 °C rating
rating
1SBC101003V0014 400 V AC-1 480 V 600 V AC
(1 pce)
AC-3
4 kW A 25 hp A 25 V 50/60 Hz V DC (2) 2 2 AF09-30-22-41 1SBL137001R4122 kg
-
5
24...60
0.320
48...130 48...130 2 2 AF09-30-22-12 1SBL137001R1222 0.320
AF26-30-11 100...250 100...250 2 2 AF09-30-22-13 1SBL137001R1322 0.320
250...500 250...500 2 2 AF09-30-22-14 1SBL137001R1422 0.360
5.5 28 7.5 28 24...60 - (2) 2 2 AF12-30-22-41 1SBL157001R4122 0.320
48...130 48...130 2 2 AF12-30-22-12 1SBL157001R1222 0.320
100...250 100...250 2 2 AF12-30-22-13 1SBL157001R1322 0.320
250...500 250...500 2 2 AF12-30-22-14 1SBL157001R1422 0.360
7.5 30 10 30 24...60 - (2) 2 2 AF16-30-22-41 1SBL177001R4122 0.320
48...130 48...130 2 2 AF16-30-22-12 1SBL177001R1222 0.320
100...250 100...250 2 2 AF16-30-22-13 1SBL177001R1322 0.320
250...500 250...500 2 2 AF16-30-22-14 1SBL177001R1422 0.360
11 45 15 45 24...60 - (2) 1 2 1 2 AF26-30-11-41 1SBL237001R4111 0.350
1SBC101004V0014 48...130 48...130 1 2 1 2 AF26-30-11-12 1SBL237001R1211 0.350
AF26-30-22-41 1SBL237001R4122
0.360
AF26-30-22-12 1SBL237001R1222
0.360
100...250
100...250
AF26-30-22-13 1SBL237001R1322
2 1 1 2 AF26-30-11-13 1SBL237001R1311 0.350
0.360
250...500 250...500 1 1 AF26-30-11-14 1SBL237001R1411 0.390
AF26-30-22 2 2 AF26-30-22-14 1SBL237001R1422 0.400
15 50 20 50 24...60 - (2) 1 1 AF30-30-11-41 1SBL277001R4111 0.350
2 2 AF30-30-22-41 1SBL277001R4122 0.360
48...130 48...130 1 1 AF30-30-11-12 1SBL277001R1211 0.350
2 2 AF30-30-22-12 1SBL277001R1222 0.360
100...250 100...250 1 1 AF30-30-11-13 1SBL277001R1311 0.350
2 2 AF30-30-22-13 1SBL277001R1322 0.360
250...500 250...500 1 1 AF30-30-11-14 1SBL277001R1411 0.390
2 2 AF30-30-22-14 1SBL277001R1422 0.400
18.5 50 25 50 24...60 - (2) 1 1 AF38-30-11-41 1SBL297001R4111 0.350
2 2 AF38-30-22-41 1SBL297001R4122 0.360
48...130 48...130 1 1 AF38-30-11-12 1SBL297001R1211 0.350
2 2 AF38-30-22-12 1SBL297001R1222 0.360
100...250 100...250 1 1 AF38-30-11-13 1SBL297001R1311 0.350
2 2 AF38-30-22-13 1SBL297001R1322 0.360
250...500 250...500 1 1 AF38-30-11-14 1SBL297001R1411 0.390
2 2 AF38-30-22-14 1SBL297001R1422 0.400
(1) For other auxiliary contacts arrangements, please contact your ABB local sales organization.
(2) For 24...60 V 50/60 Hz - 20...60 V DC, use AF..Z-30-..-21.
AF..-30-..-11 not suitable for direct control by PLC-output.
Main dimensions mm, inches AF..-30-22 119.5 4.70"
110.5 4.35" AF..-30-11 111.5 4.39"
45 1.77" 71 2.80" 10 0.39" 45 1.77" 80 3.15" 10 0.39"
35 1.38"
2 x
5.5 0.22" ø 4.2 0.17" M4 8-32 UNC 5.5 0.22"
6 0.24" 6 0.24"
80 3.15" 35 mm EN/IEC 60715 5.5 0.22" 43 1.69" 80 3.15" 60 2.36" 70 2.76" 35 mm EN/IEC 60715 5.5 0.22" 43 1.69"
5 0.20" 1SBC101373S0201 - Rev. C
AF09, AF12, AF16 AF26, AF30, AF38
5 0.20"
