Universal Motor Controller

Ordering details - Devices for extension of protection
functions

Earth fault monitors CEM11-FBP for use with Universal Motor Controller UMC100-FBP
Ordering details
Earth fault currents Through-hole Type Order code Price Weight
[mA] diameter (1 pce)
1 pce kg (lb)
80 , 300, 550, 750, 1000, 20 mm CEM11-FBP.20 1SAJ929200R0020 0.130
1)
1200, 1500, 1700 (0.287)
2CDC 345 011 F0008 2400, 3000, 3400 35 mm CEM11-FBP.35 1SAJ929200R0035 (0.441)
0.200
100 , 500, 1000, 1400, 2000,
1)
0.330
120 , 1000, 2000, 2800,
1)
1SAJ929200R0060
CEM11-FBP.60
60 mm
4000, 4800, 6000, 6800
(0.728)
1)
CEM11-FBP 300 , 2000, 4000, 5600, 120 mm CEM11-FBP.120 1SAJ929200R0120 0.940
(2.072)
8000, 9600, 12000, 13600
1) lower values have higher inaccuracy
Current transformers for use with Universal Motor Controller UMC100-FBP
Linear type transformers, 3-phase, with terminal block, for conductors Cu 2.5 mm2. For use with
UMC100 and nominal motor currents >63 A
Ordering details
Designation Recommended Type Order code Price Weight
current range
(1 pce)
2CDC 341 001 F0012 1 pce kg (lb)
1.600
1SAJ929500R0185
Current transformer
60…185 A AC
CT4L185R/4
(3.527)
1.500
Current transformer 180…310 A AC CT4L310R/4 1SAJ929500R0310
(3.307)
1.700
Current transformer 300…500 A AC CT5L500R/4 1SAJ929501R0500
CT4L185R/4, CT4L310R/4 (3.748)
Current transformer 500…850 A AC CT5L850R/4 1SAJ929501R0850 1.900
(4.189)
2CDC 341 002 F0012
12
CT5L500R/4, CT5L850R/4
