NCS125 industry current sensors
Dimensions and arrangement of right angle brackets (mm)
2
13,4 mini
102
122 125 200 121 Maxi 315 Maxi
125
31
62 8
16 21 General tolerance : ±1 mm
Ø6,5 90 Ø6,3
G0231DF
165
200
Right angle brackets mounting on NCS125 sensors
1
6
1 - Side plate: x2
5
3 - Side plate screw M6: x4 (6x30)
4 4 - Flat washer: x8
5 - Spring washer: x4
6 - Locknut: x4
A 7 - Not used:
• Side plate screw M6: x2 (6x50)
• Standard positioning screw: x2 (3x12)
A - The screws for clamping the side plates to the bar
(or cable) are not supplied
G0242DF
1
1SBC140021S0201
4
3
