P. 30
D150/31.D10 screw clamp terminal blocks
Feed-through - 31 mm 1.220 in spacing
Description
150 mm²
– Use of jumper bars requires the user to cut-out the partition,
– Closed terminal block: no end section needed, optimized rigidity,
– Ease your voltage monitoring or distribution with the two built-in derivations.
2
Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g
Feed-through Closed block Grey D150/31.D10 1SNA399715R0400 5 385.00
with 2 x 10 mm² Yellow D150/31.D10.N 1SNA399717R0600 5 385.00
Blue
1SNC161004F0014 Main technical data D150/31.D10.YL 1SNA400778R0000 5 385.00
derivations.
Mounting instructions
Rail
TH 35-7.5,
CSA
Connecting capacity
IEC
UL
TH 35-15
Main circuit with Rigid - Solid / Stranded 25-185 mm² Main circuit
1 conductor per Flexible 35-150 mm² Wire stripping 35 mm
clamp with insulated ferrule length 1.37 in
Gauge B14 Allen key
Derivation with Rigid - Solid / Stranded 0.5-16 mm² Tool Ø 8 mm
D150/31.D10
1 conductor per Flexible 0.5-10 mm² Ø 0.315 in
clamp with insulated ferrule Torque 10 - 15 N.m
Gauge B6 89 - 132 lb.in
Rated current / Rated cross section Derivation
119.4 4.70"
Main circuit 309 A / 150 mm² Wire stripping 12 mm
110 4.33" Derivation 57 A / 10 mm² length 0.47 in
Rated short-time withstand current (1s) 18000 A Flat screwdriver
Rated voltage 1000 V Tool Ø 4 mm
Impulse withstand voltage 12000 V Ø 0.157 in
114.5 4.50" Protection IP10 NEMA Torque 1.2 - 1.4 N.m
10.6 - 12.3 lb.in
The connecting capacity data for one Rigid - Solid / Stranded - Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards.
All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.abb.com
CE RoHS Gost R
36.5 1.43"
IP20 Protection with protecting cover Locking foot operating with screwdriver DIA 4 0.157 in
31 mm 1.220 in spacing
Sideopening "bistable
action".
The locking foot remains in
open or closed position.
Partition to cut to fit the wire
diameter.
Unlocking Locking
Accessories
Description Color Type Order code Pkg Weight
qty (1 pce) g
1 2 1 End stops 12 mm 0.472 in Grey BADH 1SNA116900R2700 50 24.00
2 Jumper bars 2 poles 309 A BJMI31.2 1SNA206053R0700 1 120.00
3 poles BJMI31.3 1SNA206054R0000 1 190.00
3 Protecting covers CPBP1 1SNA399788R1600 20
1SNC161029S0201 - Rev. B
3 4 4 Terminal block markersBlank card White RC1010 1SNA238000R1600 1 1.30
Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.
All the technical data for UL/CSA standard and dimensions in inches are in italic.
Technical data valid for copper conductors only.
28 | ABB SNA series - Terminal blocks
