CP-E range
Technical data

Data at Ta = 25 °C, Uin = 230 V AC and rated values, unless otherwise indicated

Type CP-E 48/0.62 CP-E 48/1.25 CP-E 48/5.0 CP-E 48/10.0

General data typ. 4.9 W typ. 7.8 W typ. 32 W typ. 60 W
Power dissipation
Efficiency typ. 86 % typ. 89 % typ. 90 %
Duty time 100 %
Dimensions (W x H x D) 83 x 123.6 x
40.5 x 90 x 114 mm 123.6 mm 175 x 123.6 x
Weight (1.59 x 3.54 x 4.49 in) (3.27 x 4.87 x 123.6 mm
Material of housing 4.87 in) (6.89 x 4.87 x
Mounting 0.264 kg (0.582 lb) 0.316 kg (0.697 lb) 1.322 kg (2.915 lb) 4.87 in) 3
Mounting position
Minimum distance to other units 1.839 kg (4.054 lb)
Degree of protection
Protection class Plastic Metal

DIN rail (IEC/EN 60715), snap-on mounting without any tool

horizontal
horizontal / vertical 25 mm / 25 mm (0.98 in / 0.98 in)
housing / terminals IP/20 / IP20

I

Electrical connection - input circuit / output circuit

Wire size fine-strand with wire end ferrule 0.2-4 mm² (24-11 AWG)
0.2-6 mm² (24-10 AWG)
fine-strand without wire end ferrule 0.2-2.5 mm² (24-14 AWG)
rigid

Stripping length 6 mm (0.24 in) 8 mm (0.31 in)
Tightening torque input / output 0.6 Nm (5 lb.in) 1.0 Nm (9 lb.in) / 0.62 Nm (5.5 lb.in)

Environmental data operation -40…+70 °C -40…+55 °C
Ambient temperature range rated load -40…+60 °C

Damp heat (cyclic) (IEC/EN 60068-2-30) storage -40…+85 °C
Vibration (sinusoidal) (IEC/EN 60068-2-6)
Shock (half-sine) (IEC/EN 60068-2-27) 95 % RH, without condensation
Isolation data
10-500 Hz, 2 G, along X, Y, Z each axis, 60 min. for each axis

15 G, 11 ms, 3 axes, 6 faces, 3 times for each face

Rated insulation voltage Ui input circuit / output circuit 3 kV AC
input / PE 1.5 kV AC
Pollution degree
Overvoltage category (UL/IEC/EN 60950-1) output / PE 0.5 kV AC; 0.71 kV DC
Standards
2

II

Product standard EN 61204-3
Low Voltage Directive 2006/95/EC
EMC directive 2004/108/EC
RoHS directive 2011/65/EC
Electrical safety EN 60950-1, UL 60950-1, UL 508, EN 61558-1, EN 61558-2-17; EN 60204-1
Protective low voltage SELV (EN 60950)
Electromagnetic compatibility

Interference immunity to IEC/EN 61000-6-2
IEC/EN 61000-4-2 Level 4 (air discharge 15 kV / contact discharge 8 kV)
electrostatic discharge IEC/EN 61000-4-3

radiated, radio-frequency, electromagnetic Level 3 (10 V/m)
field

electrical fast transient/burst IEC/EN 61000-4-4 Level 4 (4 kV / 5 kHz) Level 4 (4 kV / 2.5 kHz)

surge IEC/EN 61000-4-5 L-L Level 3 (2 kV) / L-PE Level 4 (4 kV)

conducted disturbances, induced by radio- IEC/EN 61000-4-6
frequency fields Level 3 (10 V/m)

power frequency magnetic fields IEC/EN 61000-4-8 Level 4 (30 A/m)
IEC/EN 61000-4-11
voltage dips, short interruptions and voltage
variations dip: >95 % 10 ms / >30 % 500 ms, interruptions: >95 % 5000 ms

Interference emission IEC/EN 61000-6-3 Class D
high-frequency radiated IEC/CISPR 22, EN 55022 Class B
high-frequency conducted IEC/CISPR 22, EN 55022 Class B
limits for harmonic current emissions
Class A
