CP-E range
Technical data

Data at Ta = 25 °C, Uin = 230 V AC and rated values, unless otherwise indicated

Type CP-E 24/5.0 CP-E 24/10.0 CP-E 24/20.0
Input circuit
Rated input voltage Uin L, N 115-230 V AC
Input voltage range 90-264 V AC,
115 / 230 V AC auto select 120-375 V DC
Frequency range AC
Typical input current 90-132 V AC, 90-132 V AC, 4.9 A
180-264 V AC / 180-264 V AC / 2.5 A
3 210-375 V DC 210-375 V DC 539 W
Typical power consumption 47-63 Hz 25 A (max. 5 ms)
Inrush current limiting 50 A (max. 5 ms)
at 115 V AC 2.2 A 4.0 A
Discharge current 10 A slow-acting /
at 230 V AC 0.83 A 1.55 A 250 V AC
Power failure buffering time
140 W 270 W
Internal input fuse
at 115 V AC 24 A (max. 5 ms) 30 A (max. 5 ms)

at 230 V AC 48 A (max. 5 ms) 60 A (max. 5 ms)

input / output 0.25 mA

input / PE 3.5 mA

at 115 V AC min. 25 ms

at 230 V AC min. 30 ms

3.15 A slow-acting / 6.3 A slow-acting /
250 V AC 250 V AC

Power factor correction (PFC) yes, passive, 0.7 yes, active
115 V AC: 0.99
Indication of operational states 230 V AC: 0.97
Output voltage
green LED OUTPUT OK: V: output voltage OK
red LED OUTPUT LOW: V: output voltage too low

Output circuit L+, L+, L-, L-
Rated output voltage
24 V DC

Tolerance of the output voltage 0...+1 %

Adjustment range of the output voltage 22.5-28.5 V DC

Rated output power 120 W 240 W 480 W

Rated output current Ir Ta ͨ 60 °C 5 A 10 A -
Derating of the output current 20 A
Signalling contact for output voltage OK Ta ͨ 55 °C - - -
2.5 %/°C
60 °C < Ta ͨ 70 °C 2.5 %/°C

55 °C < Ta ͨ 70 °C - -

13-14 solid-state (max. 60 V DC, 0.3 A)

Minimum fuse rating to achieve short-circuit protection 13-14 ͧ 60 V DC, ͨ 0.3 A fast-acting

Maximum deviation with load change statical ±1 % (single mode), ±5 % (parallel mode)

Control time change of output voltage within ±0.5 %
the input voltage range

< 2 ms

Starting time after applying the supply voltage at Ir max. 1 s
with 3500 μF max. 1.5 s
- -

with 7000 μF - max. 1.5 s

Rise time at rated load max. 150 ms

with 3500 μF max. 500 ms - -

with 7000 μF - max. 500 ms

Fall time max. 150 ms

Residual ripple and switching peaks BW = 20 MHz 50 mV 100 mV

Parallel connection configurable, to increase power, up to 3 devices, min. 0.1 Ir - max. 0.9 Ir

Series connection yes, to increase voltage, max. 2 devices

Resistance to reverse feed max. 35 V DC

Output circuit - No-load, overload and short-circuit behaviour U/I characteristic curve
Characteristic curve of output
Short-circuit protection continuous short-circuit proof
Short-circuit behaviour
Overload protection continuation with output power limiting
No-load protection
Starting of capacitive loads output power limiting

continuous no-load stability

3500 μF 7000 μF
