CP-E range
Ordering details

                                                      Description

                                                      This range offers types with output voltages from 5 V DC to 48 V DC at output currents of
                                                      0.625 A to 20 A. The high thermal efficiency of up to 90 %, corresponding to very low power
                                                      and heat dissipation, allows operation without forced cooling. The functionality has been en-
                                                      hanced while the number of different types has been considerably reduced.
                                                      Of course all power supplies of the CP-E range are approved in accordance with all relevant
                                                      international standards.

                                                                                                                                                                3

                                                      Ordering details - CP-E < 100 W

                                                      Input voltage range          Rated output       Type          Order code       Price  Weight
                                                                                   voltage / current                                 1 pce  (1 pce)
                                                                                                                    1SVR427033R3000         kg (lb)
                                                                                                                    1SVR427032R1000
              2CDC 271 017 F0006                      90-264 V AC / 120-375 V DC   5 V DC / 3 A       CP-E 5/3.0    1SVR427035R1000         0.15
                                                                                   12 V DC / 2.5 A    CP-E 12/2.5   1SVR427030R0000         (0.33)
CP-E 24/0.75                                          85-264 V AC / 90-375 V DC    12 V DC / 10 A     CP-E 12/10.0  1SVR427031R0000
CP-E 12/2.5                                           90-132 V AC, 180-264 V AC /  24 V DC / 0.75 A   CP-E 24/0.75  1SVR427032R0000         0.29
CP-E 48/5.0                                           210-375 V DC                 24 V DC / 1.25 A   CP-E 24/1.25                          (0.64)
                                                      90-264 V AC / 120-375 V DC   24 V DC / 2.5 A    CP-E 24/2.5
                                                                                                                                            1.00
                                                      85-264 V AC / 90-375 V DC                                                             (2.20)

                                                      85-264 V AC / 90-375 V DC                                                             0.15
                                                                                                                                            (0.33)

                                                                                                                                            0.29
                                                                                                                                            (0.64)

                                                                                                                                            0.36
                                                                                                                                            (0.79)

                                                      Ordering details - CP-E M 120 W

                                                      Input voltage range          Rated output       Type          Order code       Price  Weight
                                                                                   voltage / current                                 1 pce  (1 pce)
                                                                                                                                            kg (lb)

                                  2CDC 271 013 F0006  90-132 V AC, 180-264 V AC /  24 V DC / 5 A      CP-E 24/5.0   1SVR427034R0000         1.00
                                                      210-375 V DC                 24 V DC / 10 A     CP-E 24/10.0                          (2.20)
                                                      90-132 V AC, 180-264 V AC /  24 V DC / 20 A     CP-E 24/20.0
                                  2CDC 271 028 F0008  210-375 V DC                 48 V DC / 0.625 A  CP-E 48/0.62  1SVR427035R0000         1.36
                                                                                   48 V DC / 1.25 A   CP-E 48/1.25  1SVR427036R0000         (3.01)
                                                      90-264 V AC / 120-375 V DC   48 V DC / 5 A      CP-E 48/5.0   1SVR427030R2000
                                                                                   48 V DC / 10 A     CP-E 48/10.0  1SVR427031R2000         1.90
                                                      85-264 V AC / 90-375 V DC                                     1SVR427034R2000         (4.18)
                                                                                                                    1SVR427035R2000
                                                      85-264 V AC / 90-375 V DC                                                             0.29
                                                                                                                                            (0.64)
                                                      90-132 V AC, 180-264 V AC /
                                                      210-375 V DC                                                                          0.36
                                                                                                                                            (0.79)
                                                      90-264 V AC / 120-375 V DC
                                                                                                                                            1.36
                                                                                                                                            (3.01)

                                                                                                                                            1.90
                                                                                                                                            (4.19)
