AC500-XC
Ordering data

Hot swap terminal units
For loadless hot swapping of digital and analog expansion modules, when used in configurations with
communication interface modules or AC500 CPU supporting hot swap. Hot swapping of attached ex-
pansion module mounted on hot swap terminal unit is supported by AC500 V3 CPU modules as of
PM5630-2ETH, AC500 V2 CPU modules as of PM585-ETH, CI501-PNIO, CI502-PNIO, CI541-DP, CI542-DP,
CI521-MODTCP and CI522-MODTCP. AC500-S safety I/O modules cannot be used in configurations con-
taining hot swap terminal units. Mixed configurations of hot swap terminal units with normal terminal
units for digital and analog expansion modules are possible. In the installation hot swap terminal units
can be idenfied by the word Hot Swap and a white frame around the connection terminal area.

For Supply Connection type Type Order code Price Weight
(1 pce)
kg
I/O modules - for Hot Swap (2) 24 V DC Spring TU516-H-XC 1SAP415000R0001 0.300
I/O modules AC / Relay - for Hot Swap (2) 230 V AC Spring TU532-H-XC 1SAP415100R0001 0.300
I/O module DO526-XC - for Hot Swap (2) 24 V DC Spring TU542-H-XC 1SAP415200R0001 0.300
(2) I/O module as of index F0 needed for Hot Swap

05
Terminal units
For digital and analog expansion modules and interface modules. Please note: for modules with relay
outputs, terminal units for 230 V AC (TU532-XC) is required.
For Supply Connection type Type Order code Price Weight
(1 pce)
kg
Ethernet interface modules 24 V DC Spring TU508-ETH-XC 1SAP414000R0001 0.300
CANopen/PROFIBUS DP interface modules 24 V DC Spring TU510-XC 1SAP410800R0001 0.300
I/O modules 24 V DC Spring TU516-XC 1SAP412000R0001 0.300
CANopen/PROFIBUS DP interface modules 24 V DC Spring TU518-XC (1) 1SAP411200R0001 0.300
Ethernet gateway modules 24 V DC Spring TU520-ETH-XC 1SAP414400R0001 0.300
I/O modules AC / Relay 230 V AC Spring TU532-XC 1SAP417000R0001 0.300
I/O module DO526-XC 24 V DC Spring TU542-XC 1SAP413200R0001 0.300
CS31 interface modules 24 V DC Spring TU552-CS31-XC 1SAP410400R0001 0.300
(1) TU518-XC Terminal units can also be used with PROFIBUS DP CI modules with baud rate up to 1Mbaud.
(2) I/O module as of index F0 needed for Hot Swap

— — — — —
TU516-XC TU520-ETH-XC TU510-XC TU508-ETH-XC TU516-H-XC
