ABB L'essentiel du tableautier – Distribution électrique basse tension | 29

Caractéristiques Article Réf. internationale @ Désignation Col.
3P 1250 A 945391 1SCA112676R1001 INVERS.MOTOR. OTM1250E3CM230C 1
4P 1250 A 945394 1SCA112702R1001 INVERS.MOTOR. OTM1250E4CM230C 1
3P 1600 A 945393 1SCA112678R1001 INVERS.MOTOR. OTM1600E3CM230C 1
4P 1600 A 945396 1SCA112704R1001 INVERS.MOTOR. OTM1600E4CM230C 1
Modules de gestion normal/secours
Réseau/réseau
Modulaire gestion alimentation 954880 1SCA122946R1001 ALIM. ODPS230 automatic 1
double intégré
Réseau/réseau ou réseau/groupe
OMD300 LED gestion alimentation 954537 1SCA123790R1001 OMD300E480C-A1 1
Fuse Fuse
double intégré
OMD800 LCD fonction ARU + Modbus 954538 1SCA123791R1001 OMD800E480C-A1 1
Alimentation moteur
230 V AC gestion alimentation 950271 1SCA116892R1001 ALIM. Inverseur ODPSE230C 1
double - uniquement
pour OMD800
Accessoires
Kits de pontage
4P 160 A-250 A 925252 1SCA022767R7040 CONNEXION INVERS. OTZC14 1
4P 400 A 925254 1SCA022767R7210 CONNEXION INVERS. OTZC24 1
4P 630 A 925601 1SCA022785R7110 CONNEXION INVERS. OTZC34 1
3P 1000 A-1250 A 933675 1SCA022868R0710 CONNEXION INVERS. OTZC43 1
4P 1000 A-1250 A 933676 1SCA022868R0800 CONNEXION INVERS. OTZC44 1
3P 1600 A 933677 1SCA022868R0980 CONNEXION INVERS. OTZC53 1
4P 1600 A 933678 1SCA022868R1010 CONNEXION INVERS. OTZC54 1
Contacts auxiliaires (8 max, 4 par inter)
1NO montage droite 910244 1SCA022353R4970 CONTACT AUXILIAIRE OA1G10 1
1NF montage droite 914199 1SCA022456R7410 CONTACT AUXILIAIRE OA3G01 1
Cache-bornes
4P 160 A-250 A 923702 1SCA022731R8230 OTS250G1L/4 1
4P 400 A 923865 1SCA022736R9490 OTS400G1L/4 1
4P 630 A 925288 1SCA022776R7970 OTS800G1L/4 1
3P 1000 A-1600 A 933878 1SCA022871R9510 OTS1600G1L/3 1
4P 1000 A-1600 A 933880 1SCA022871R9780 OTS1600G1L/4 1
Kits prise de tension pour inverseurs
4P OTM160…250_C 951740 1SCA120153R1001 OMZB18 1
4P OTM315…400_C 951741 1SCA120154R1001 OMZB28 1
4P OTM630…800E_C 951742 1SCA120155R1001 OMZB38 1
4P OTM1000…1600_C 951743 1SCA120156R1001 OMZB48 1
Inverseurs de source motorisés autopilotés - OTM_C_D (avec module de gestion normal/secours intégré)
Montage sur platine - In>160 A
ATS 300 + inverseur + poignée + kit prise tension
4P 160 A 940091 1SCA106305R1001 INVERS.AUTO. OTM160E4C3D230C 1
4P 250 A 940085 1SCA106313R1001 INVERS.AUTO. OTM250E4C3D230C 1
4P 400 A 940090 1SCA106318R1001 INVERS.AUTO. OTM400E4C3D230C 1
4P 630 A 941961 1SCA108726R1001 INVERS.AUTO. OTM630E4C3D230C 1
4P 1000 A 945497 1SCA112852R1001 INVERS.AUTO. OTM1000E4C3D230C 1
ATS 800 (LCD + ARU + MODBUS) + inverseur + poignée + kit prise tension
4P 160 A 935947 1SCA101020R1001 INVERS.AUTO. OTM160E4C8D230C 1
4P 250 A 935949 1SCA101022R1001 INVERS.AUTO. OTM250E4C8D230C 1
4P 400 A 935989 1SCA101064R1001 INVERS.AUTO. OTM400E4C8D230C 1
4P 630 A 941819 1SCA108453R1001 INVERS.AUTO. OTM630E4C8D230C 1
4P 1000 A 945506 1SCA112861R1001 INVERS.AUTO. OTM1000E4C8D230C 1
4P 1250 A 945509 1SCA112864R1001 INVERS.AUTO. OTM1250E4C8D230C 1
4P 1600 A 945512 1SCA112867R1001 INVERS.AUTO. OTM1600E4C8D230C 1
Accessoires 05
Kits de pontage
4P 160 A-250 A 925252 1SCA022767R7040 CONNEXION INVERS. OTZC14 1
4P 400 A 925254 1SCA022767R7210 CONNEXION INVERS. OTZC24 1
4P 630 A 925601 1SCA022785R7110 CONNEXION INVERS. OTZC34 1
4P 1000 A-1250 A 933676 1SCA022868R0800 CONNEXION INVERS. OTZC44 1
4P 1600 A 933678 1SCA022868R1010 CONNEXION INVERS. OTZC54 1
Alimentation
230 V AC gestion alimentation 950271 1SCA116892R1001 ALIM. inverseur ODPSE230C 1
double - uniquement
pour ATS800
Contacts auxiliaires (8 max, 4 par inter)
1NO Montage à droite 910244 1SCA022353R4970 CONTACT AUXILIAIRE OA1G10 1
1NF Montage à droite 914199 1SCA022456R7410 CONTACT AUXILIAIRE OA3G01 1
Cache-bornes
4P 160 A-250 A 923702 1SCA022731R8230 OTS250G1L/4 1
4P 400 A 923865 1SCA022736R9490 OTS400G1L/4 1
4P 630 A 925288 1SCA022776R7970 OTS800G1L/4 1
4P 1000 A-1600 A 933880 1SCA022871R9780 OTS1600G1L/4 1
