Voltage transformers application
®
ESSAILEC pre-wired plugs for voltage transformers

Compatible
Ordering details products
Description Type Part Number Pkg Weight Socket
qty 1 pce g
Plug 2x4 poles
1 plug 2x4 pins PRECODED 2.2 / Grey COR-T-R5-2.2 1SNA167933R1600 1 1070 TC-E-VA
4 x Ø 4 mm test plugs / Black TC-E-VA-2.2
4 x Ø 4 mm test plugs / Red TC-E-VA-R2-2.2
Conductors section: 2.5 mm² TC-DS-VL
cable length: 2 m / 79" TC-S-INF-VL-2.2
TC-D-VA
TC-TH35-VL
TC-E-C5A-2.2
TO-E-VA
TO-E-VA-12.12
TO-DS-VL
TO-S-INF-VL-12.12
TO-D-VA
1 plug 2x4 pins PRECODED 8.8 / Blue COR-P-R1-8.8 1SNA166978R0000 1 1080 PC-E-VA
4 x Ø 4 mm test plugs / Black PC-E-VA-8.8
4 x Ø 4 mm test plugs / Red PC-DS-VL
Conductors section: 2.5 mm² PC-D-VA
cable length: 2 m / 79" PO-E-VA
PO-DS-VL
PO-D-VA
PC-E-VA
PC-E-VA-8.8
PC-DS-VL
PC-D-VA
PO-E-VA
PO-DS-VL
PO-D-VA
4 Plug 4 poles
1 plug 4 pins / Grey COR-T-4-4 1SNA167935R1000 1 500 TC-E-VA
Design for insertion 01-02-03-04 (D. TC-E-VA-2.2
design.) TC-E-VA-R2-2.2
4 x Ø 4 mm test plugs / Black TC-DS-VL
Conductors section: 2.5 mm² TC-S-INF-VL-2.2
cable length: 2 m / 79" TC-D-VA
TC-TH35-VL
TC-E-C5A-2.2
TO-E-VA
TO-E-VA-12.12
TO-DS-VL
TO-S-INF-VL-12.12
TO-D-VA
TF-E-VA
TF-DS-VL
TF-D-VA

1SNC169025S0201
