D4/8.SF.I.ADO IDC terminal blocks
For 5 x 20 and 5 x 25 fuses - with test socket ADO - screw clamp 8 mm 0.315 in spacing

Description
2.5 mm²
– Protect your circuits with 5 x 20 and 5 x 25 fuse terminal blocks (fuse not delivered with the terminal blocks),
14 AWG – Quickly identify the defective circuit thanks to blown fuse indicators,
®
– With the TE Connectivity ADO System , experience the fastest and most reliable connection on the market,
®
– This solution brings all the benefits of the ADO System and allows installators to connect on standard screw
clamp,
– Up to 2 wires per connection in the ADO System connection.
®
1SNC163123F0014 Ordering details Color Type Part Number Pkg Weight
Description
Fuse With blown fuse indicator by Grey D4/8.SFLT2.I.ADO2 1SNA399768R2100 pce (1 pce) g
50
13.00
neon 110 - 230 V AC and 2 test
sockets DIA 2 mm 0.079 in,
2
D4/8.SF.I.ADO with black marking for wire size
1-2.5 mm² (16-14 AWG)
With blown fuse indicator by Grey D4/8.SFDT2.I.ADO2 1SNA399770R2700 50 13.00
LED 24 V AC/DC and 2 test
sockets DIA 2 mm 0.079 in,
68.2 2.68" with black marking for wire
size 1-2.5 mm² (16-14 AWG)
180°
Main technical data Mounting instructions
94 3.70" 86.5 3.40" 55.9 2.20" 48.4 1.90" IEC UL CSA Rail TH 35-7.5,
TH 35-15
Rigid: Solid/Stranded
ADO
1-2.5 mm²
0.37 in
length
Flexible without ferrule 1-2.5 mm² Wire stripping 9.5 mm
Screw clamp Rigid: Solid/Stranded 0.2-4 mm² Tool Flat screwdriver
25.5 1.00"
Flexible without ferrule 0.22-4 mm² Ø 4 mm
Flexible with insulated ferrule Ø 0.157 in
Gauge A4
8 mm 0.315 in spacing Rated current / Rated cross section 6.3 A / 2.5 mm²
Rated short-time withstand current (1s) 300 A Torque 0.5 - 0.8 N.m
Rated voltage 500 V 4.4 - 7.1 lb.in
Impulse withstand voltage 6000 V
Protection IP20 NEMA 1
The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
RoHS Gost R
Leakage current: 24 V < 4.5 mA; 110 V < 0.5 mA; 230 V < 0.7 mA
Accessories
1 2 Description Color Type Part Number Pkg Weight
pce (1 pce) g
1 End stops 10 mm 0.394 in Dark grey BAM4 1SNK900001R0000 50 14.00
5.2 mm 0.205 in BAZ1 1SNK900002R0000 50 5.30
3 4 2 End sections 1.5 mm 0.059 in Grey FEDAD10 1SNA399758R2700 20 3.00
3 Lateral jumper bars 10 poles 35 A PC81-10 1SNA173523R1100 10 5.00
4 Test plugs DIA 2 mm 0.079 in Black FC2 1SNA007865R2600 100
5 Fuses 0.5 A FU520 1SNA008288R1500 10
1 A 1SNA008290R1300 10
5 6 2 A 1SNA008291R0000 10
3.15 A 1SNA008289R1600 10
5 A 1SNA008292R0100 10
6 Assembly rods 2 poles TGA8 1SNA168672R1100 10 1.00
3 poles 1SNA168673R1200 10
7 8
4 poles 1SNA168674R1300 10
7 Spring retaining rings ANT 1SNA168675R1400 10
8 Tools Semi automatic tool OUPAD 1SNA178944R0400 1 205.00
Hand tool OUMAD 1SNA179466R0600 1 29.00
9 9 Terminal block markers Blank card White RC810 1SNA234000R0200 1 8.20
Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.
