D1/5.ADO IDC terminal blocks
Feed-through ADO - ADO - 5 mm 0.197 in spacing

Description
1 mm²
®
– With the TE Connectivity ADO System , experience the fastest and most reliable connection on the market,
18 AWG – Designed for control applications exposed to severe constrains (vibrations, shocks, corrosion etc.),
– Up to 2 wires per connection.
Ordering details
Description Color Type Part Number Pkg Weight
pce (1 pce) g
Feed-through
50
Feed-through
Grey
1SNA199563R2400
D1/5.ADO
5.00
1SNC163001F0014 Orange D1/5.N.ADO 1SNA199565R2600 50 5.00
Blue
D1/5.ADO
50
1SNA199564R2500
5.00
Main technical data
IEC UL CSA Mounting instructions
Rail
TH 35-7.5,
TH 35-15 2
ADO Rigid: Solid/Stranded 0.2-1 mm² 22-18 AWG Wire stripping
Flexible without ferrule 0.22-1 mm² length
D1/5.ADO
Screw clamp Rigid: Solid/Stranded Tool
Flexible without ferrule
Flexible with insulated ferrule
45.5 1.79" Gauge
Rated current / Rated cross section 13.5 A / 1 mm² 7 A / 18 AWG
Rated short-time withstand current (1s) 120 A Torque
Rated voltage 1000 V 600 V
56 2.20" 48.5 1.91" Impulse withstand voltage 8000 V NEMA 1
Protection
IP20
The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
C US
RoHS cCSAus Gost R
24 0.95"
5 mm 0.197 in spacing
Accessories
Description Color Type Part Number Pkg Weight
pce (1 pce) g
1 2
1 End stops 10 mm 0.394 in Dark grey BAM4 1SNK900001R0000 50 14.00
5.2 mm 0.205 in BAZ1 1SNK900002R0000 50 5.30
2 End sections 3 mm 0.118 in Grey FEMAD3 1SNA199341R0500 20 2.50
3 Jumper bars 2 poles 24 A BJMI5-2 1SNA176278R1600 10 3.30
3 4 3 poles BJMI5-3 1SNA176279R1700 10 5.00
4 poles BJMI5-4 1SNA176280R0500 10 6.70
5 poles BJMI5-5 1SNA176281R2200 10 8.40
10 poles BJMI5-10 1SNA176282R2300 10 16.90
4 Circuit separators 0 mm 0 in Grey SCAD5 1SNA199551R2000 10 0.30
5 6
5 Shield connectors CBM5 1SNA178745R1400 50
6 Tools Semi automatic tool OUPAD 1SNA178944R0400 1 205.00
Hand tool OUMAD 1SNA179466R0600 1 29.00
7 Terminal block markers Blank card White RC510 1SNA231000R0700 1 5.20
7 Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.

1SNC163039S0201 - Rev. A

Ground IDC terminal blocks
Description Color Type Part Number Pkg Weight
pce (1 pce) g
Ground Profile aligned with D1/5.ADO Green-yellow D1/5.P.ADO 1SNA399031R2200 50 9.00
Technical data valid for copper conductors only.
