AF116 ... AF370 4-pole contactors

with 1 N.O. + 1 N.C. auxiliary contacts
Main accessories

Main accessories (other accessories available)

CAL19-11B
2-pole auxiliary
contact block

5
VM
Mechanical
interlock

AF contactor
CAL19-11B with bar connections
2-pole auxiliary LT
contact block Terminal shroud

AF contactor
with built-in cable clamps

Main accessory fitting details
Contactor Main Available Side-mounted accessories
types poles auxiliary Auxiliary contact blocks
contacts

Mechanical interlock units
CAL19-11 CAL19-11B (between two contactors)

AF116 ... AF370 4 0 1 1 1 x CAL19-11 + 2 x CAL19-11B –

AF116 ... AF370 4 0 1 1 – + 2 x CAL19-11B (1) + VM... (2)

(1) Total number of auxiliary contact blocks for the two contactors. (2) Interlock type, according to the contactor ratings (see "Accessories").
