AF116 ... AF370 4-pole contactors

with 1 N.O. + 1 N.C. auxiliary contacts
Main accessories

Ordering details (1)
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

1SFC101071V0001 Side-mounted instantaneous auxiliary contact blocks kg

AF116 ... AF370 1 1 CAL19-11 1SFN010820R1011 2 0.050
CAL19-11 1 1 CAL19-11B 1SFN010820R3311 2 0.050

Mechanical interlock unit
AF116 ... AF370 VM19 1SFN030300R1000 1 0.054
AF116 ... AF146 and AF190, AF205 VM140/190 1SFN034403R1000 1 0.088
AF190, AF205 and AF265 ... AF370 VM205/265 1SFN035203R1000 1 0.090

Terminal shrouds 5
AF116 … AF140, with compression lugs LT140-40L 1SFN124203R2000 2 2 0.090
1SFN124801R2000
LT205-40C
1SFC101035V0001 AF190 … AF205, with compression lugs LT205-40L 1SFN124803R2000 2 2 0.290
AF190 … AF205, with cable clamps
0.060
0.040
1SFN125401R2000
LT370-40C
AF265 … AF370, with cable clamps
VM19 AF265 … AF370, with compression lugs LT370-40L 1SFN125403R2000 2 0.370
For contactors Dimensions Type Order code Pkg Weight
qty (1 pce)
hole Ø bar
mm mm kg
Terminal enlargements
AF190 … AF205 10.5 20 x 5 LW205-40 1SFN074807R2000 1 0.306
AF265 … AF370 10.5 25 x 5 LW370-40 1SFN075407R2000 1 0.540
(1) For more information, refer to "Accessories" section.
