AC500-eCo
Ordering data

Description Communication Type Order code Price Weight
type (1 pce)
kg
Option board for serial communication extension
RS232 serial adapter isolated, 5 pole spring/cable front terminal RS232 isolated TA5141-RS232I 1SAP187300R0001 0.150
3.50 mm pitch
RS485 serial adapter isolated, 5 pole spring/cable front terminal RS485 isolated TA5142-RS485I 1SAP187300R0002 0.150 03
3.50 mm pitch
RS485 serial adapter non isolated, 5 pole spring/cable front terminal RS485 not TA5142-RS485 1SAP187300R0003 0.150
3.50 mm pitch isolated
Option board for communication address setting or real time clock
KNX address switch option board, 1 push button - TA5130-KNXPB 1SAP187200R0001 0.150
Real Time Clock without battery, option board for AC500-eCo Basic - TA5131-RTC 1SAP187200R0002 0.150
CPU only
The necessary spring terminal blocks are delivered with each option board. Only ABB terminal blocks must be used with AC500-eCo V3.

— — — —
TA5141-RS232I TA5142-RS485I TA5142-RS485 TA5130-KNXPB

Description Type Order code Price Weight
(1 pce)
kg
Spare parts for option boards (terminal blocks)
TA5220-SPF5:S500, terminal block, 5 pole, spring front/cable front, pitch 3.5mm, TA5220-SPF5 1SAP187400R0012 0.150
pack.unit: 6 piece
TA5220-SPF6:S500, terminal block, 6 pole, spring front/cable front, pitch 3.5mm, TA5220-SPF6 1SAP187400R0013 0.170
pack.unit: 6 piece
TA5220-SPF7:S500, terminal block, 7 pole, spring front/cable front, pitch 3.5mm, TA5220-SPF7 1SAP187400R0014 0.180
pack.unit: 6 piece
TA5220-SPF8:S500, terminal block, 8 pole, spring front/cable front, pitch 3.5mm, TA5220-SPF8 1SAP187400R0015 0.200
pack.unit: 6 piece
TA5220-SPF9:S500, terminal block, 9 pole, spring front/cable front, pitch 3.5mm, TA5220-SPF9 1SAP187400R0016 0.230
pack.unit: 6 piece
Only ABB terminal blocks must be used with AC500-eCo V3.

— — — — —
TA5220-SPF5 TA5220-SPF6 TA5220-SPF7 TA5220-SPF8 TA5220-SPF9
