Coordination des protections

Filiation

MCCB (XT) - MCB (S200&SN201) @ 415 V
R S T R S T N R S T N R S T N R S T
XT4 XT4 XT4 XT4 XT4

S203 S202 S204 S202 S202

Amont XT1 XT1 XT1 XT2 XT3 XT4 XT1 XT2 XT3 XT4 XT1 XT2 XT4 XT2 XT4 XT2 XT4 T5
Courbe B C N S H L V –
Icu [kA] @ 415 V 18 25 36 50 70 120 150 –
Aval In [A] – – – – – – – – –
S200 B, C, K, Z 10 0.5 ... 10 18 25 30 36 36 30 30 36 40 30 30 40 30 40 30 40 30 20
13 ... 63 18 25 30 36 16 30 30 36 16 30 30 40 30 40 30 40 30 20
S200M B, C, D, K, Z 15 0.5 ... 10 18 25 30 36 36 30 30 40 40 30 30 40 30 40 30 40 30 20
13 ... 63 18 25 30 36 25 30 30 40 25 30 30 40 30 40 30 40 30 20
S200P B, C, D, K, Z 25 0.5 ... 10 – – 30 36 36 30 30 50 40 30 30 60 30 60 30 60 30 –
13 ... 25 – – 30 36 30 30 30 40 30 30 30 40 30 40 30 40 30 –
15 32 ... 63 18 25 30 36 25 30 30 40 25 30 30 40 30 40 30 40 30 –
S800B B, C 16 32 ... 100 18 25 36 36 36 36 36 50 36 50 36 70 70 120 120 150 150 20
D, K 125* 18 25 36 36 36 36 36 50 36 50 36 70 70 120 120 150 150 20
S800C B, C, D, K 25 10 ... 125 – – 36 36 36 36 40 50 40 50 40 70 70 120 120 150 150 –
S800N B, C, D 36 10 ... 125 – – – – – – 50 50 50 50 50 70 70 120 120 150 150 –
S800S B, C, D, K 50 10 ... 125 – – – – – – – – – – – 70 70 120 120 150 150 –
F200 16 ... 63 15 15 15 15 – – 15 15 – – 15 15 – 15 – 15 – –
80 ... 100 10 10 10 10 – – 10 10 – – 10 10 – 10 – 10 – –

MCCB - MCCB @ 415 V
R S T N R S T
XT4 XT4

XT2 XT2

Amont XT1 XT2 XT3 XT4 T5 T6 XT1 XT2 XT3 XT4 T5 T6 T7 XT1 XT2 XT4 T5 T6 T7 XT2 XT4 T5 T6 T7 XT2 XT4 T5
Version C N N S H L V
Aval Icu [kA] 25 36 36 50 70 120 100 (1) 150 200
XT1 B 18 25 36 36 36 36 36 30 30 36 50 50 50 36 36 36 40 70 50 40 40 40 70 65 50 50 – 70 70 70
XT1 C 25 – 36 36 36 36 36 36 36 40 50 50 50 50 50 50 50 70 65 65 65 50 70 70 70 70 50 70 70 70
XT1 N 36 – – – – – – – – 50 50 50 50 50 50 50 65 70 65 65 65 50 70 70 70 70 70 70 70 70
XT2 – – – – – – – – – 50 50 50 50 50 50 – 70 65 65 65 65 100 100 100 85 85 120 120 120
XT3 – – – – – – – – – – 50 50 50 50 50 – – 65 65 65 50 – 100 100 100 50 – 120 120
XT4 – – – – – – – – – – – 50 50 50 40 – – 65 65 65 50 – 100 100 65 65 – 120 120
T5 – – – – – – – – – – – – 50 50 50 – – – 65 65 50 – – 100 85 65 – – 120
T6 – – – – – – – – – – – – – 50 40 – – – – 65 40 – – – 70 50 – – –
XT1 S 50 – – – – – – – – – – – – – – – 70 70 70 70 70 70 70 70 70 70 70 70 70 70
XT2 – – – – – – – – – – – – – – – – – 70 70 70 70 100 100 100 85 85 150 130 130
XT3 – – – – – – – – – – – – – – – – – 70 70 70 – – 100 100 100 – – 150 150
XT4 – – – – – – – – – – – – – – – – – 70 70 70 70 – 100 100 85 85 – 150 150
T5 – – – – – – – – – – – – – – – – – – 70 70 70 – – 100 85 85 – – 150
T6 – – – – – – – – – – – – – – – – – – – 70 – – – – 85 85 – – –
XT1 H 70 – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
XT2 – – – – – – – – – – – – – – – – – – – – – 120 120 120 85 85 150 150 150
XT4 – – – – – – – – – – – – – – – – – – – – – – 120 120 100 100 – 150 150
T5 – – – – – – – – – – – – – – – – – – – – – – – 120 100 100 – 180 180
T6 – – – – – – – – – – – – – – – – – – – – – – – – 100 85 – – –
XT2 L 120 – – – – – – – – – – – – – – – – – – – – – – – – – – 150 150 150
XT4 – – – – – – – – – – – – – – – – – – – – – – – – – – – 150 150
T5 – – – – – – – – – – – – – – – – – – – – – – – – – – – – 200
(1) 120 kA pour T7
