SNA series, terminal blocks
Screw clamp technology
Overview 13
Feed-through
2.5 mm² / 12 AWG MA2.5/5 14
4 mm² / 10 AWG M4/6 16 2
M4/6.3A & M4/6.4A 3 & 4 connections 18
6 mm² / 8 AWG M6/8 20
10 mm² / 6 AWG M10/10 22
16 mm² / 6 AWG M16/12 24
35 mm² / 0 AWG M35/16 25
70 mm² / 00 AWG D70/22 26
95 mm² / 0000 AWG D95/26 27
150 mm² D150/31.D10 28
240 mm² D240/36.D10 29
Ground
2.5 mm² / 12 AWG MA2.5/5.P & D2.5/5.P 30
4 mm² / 12 AWG M4/6.P & D4/6.P 32
M4/6.3A.P & M4/6.4A.P 3 & 4 connections 34
6 mm² / 8 AWG M6/8.P & D6/8.P 36
10 mm² / 6 AWG M10/10.P 38
16 mm² / 4 AWG M16/12.P 39
35 mm² / 0 AWG M35/16.P 40
70 mm² / 00 AWG D70/22.P 41
95 mm² / 0000 AWG D95/26.P 42
Double deck
2.5 mm² / 12 AWG MA2.5/5.D2 44
4 mm² / 12 AWG M4/6.D2 46
M4/6.D1 circuit One 48
6 mm² / 8 AWG M6/8.D2 50
2.5 mm² / 12 AWG D2.5/5.DP Double deck + ground 52
Triple deck
2.5 mm² / 12 AWG D2.5/6.DA 53
4 mm² / 12 AWG D4/6.T 54
D4/6.P.T1 7 connections for grounding 56
Disconnect
2.5 mm² / 12 AWG MA2.5/5.SNB 58
4 mm² / 10 AWG M4/6.SNB 60
6 mm² / 8 AWG M6/8.SNB 62
4 mm² / 12 AWG M4/6.D2.SNBT Double deck, disconnect 63
4 mm² / 10 AWG M4/6.SB & M6/8.SB Disconnect with plug 64
4 mm² M4/6.D2.SB Double deck, disconnect with plug 66
6 mm² / 8 AWG M6/8.STP Disconnect with push-turn knob 67
M6/8.STP3 Feed-through - profile aligned with M6/8.STP 69
M6/8.ST Test disconnect with screwdriver sliding link 70
M6/8.ST7 Feed-through - profile aligned with M6/8.ST 75
For 5x20 and 5x25 mm fuses (0.197x0.787 in and 0.197x0.984 in)
4 mm² / 12 AWG M4/8.SF holders Fuse 76
M4/8.SN Disconnect - profile aligned with M4/8.SF 80
M4/8 Feed-through - profile aligned with M4/8.SF 81
M4/8.D2.SF Double deck, fuse holder 82
D4/8.D2.P.SF Double deck, fuse holder, ground 84
For 6.3x25 and 6.3x32 mm fuses (¼ x 1 in and ¼ x 1¼ in) 1SNC161120S0201
10 mm² / 10 AWG ML10/13.SF 86
ML10/13.SN Disconnect - profile aligned with ML10/13.SF 88
