M4/8.SF screw clamp terminal blocks

For 5x20 and 5x25 fuses - 8 mm 0.315 in spacing

4 mm² Standard block
12 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g 2
Fuse Orange M4/8.SF2 1SNA105135R1100 50 14.00

Main technical data IEC UL CSA Nota
Rated voltage 630 V 600 V
Impulse withstand voltage 8000 V
Protection IP20 NEMA 1

CE RoHS USR Gost R

8 mm 0.315 in spacing

4 mm² With 2 test socket DIA 2 mm 0.079 in
12 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g
Fuse With 2 test socket Grey M4/8.SFT 1SNA115662R2200 50 14.00
DIA 2 mm 0.079 in

Main technical data IEC UL CSA Nota
Rated voltage 400 V 600 V 250 V
Impulse withstand voltage 4000 V
Protection IP20 NEMA 1
CE RoHS USR CSA Gost R
Accessories
8 mm 0.315 in spacing Description Color Type Order code Pkg Weight
qty (1 pce) g
1 Test plugs DIA 2 mm 0.079 in Black FC2 1SNA007865R2600 100
1

1SNC161104S0201 - Rev. A

All the technical data for UL/CSA standard and dimensions in inches are in italic.
Technical data valid for copper conductors only.
ABB SNA series - Terminal blocks | 77
