Page 19 - 1SNC160019C0203_SNA series - Terminal blocks
P. 19
M4/6 screw clamp terminal blocks
Feed-through - 6 mm 0.236 in spacing
4 mm² With partition
10 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g 2
Feed-through With partition Grey M4/6.1 1SNA115259R0600 50 8.20
Orange M4/6.1 1SNA105208R1300 50 8.20
Main technical data IEC UL CSA Nota
Rated voltage 1000 V 600 V 600 V
Impulse withstand voltage 8000 V
Protection IP20 NEMA 1
6 mm 0.236 in spacing CE RoHS USR CSA Gost R
Accessories
Description Color Type Order code Pkg Weight
1 2 qty (1 pce) g
1 Test sockets DIA 2 mm 0.079 in AL2 1SNA163043R2100 50 0.90
DIA 3 mm 0.120 in AL3 1SNA163261R0000 50 1.20
DIA 4 mm 0.157 in AL4-M3 1SNA206721R0100 50 1.10
2 Test plugs DIA 2 mm 0.079 in Black FC2 1SNA007865R2600 100
4 mm² With test socket DIA 2 mm 0.079 in
10 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g
Feed-through With test socket Grey M4/6.2 1SNA115217R1400 50 8.20
DIA 2 mm 0.079 in
Main technical data IEC UL CSA Nota
Rated voltage 800 V 600 V 600 V
Impulse withstand voltage 8000 V
Protection IP20 NEMA 1
6 mm 0.236 in spacing CE RoHS USR CSA Gost R
Accessories
Description Color Type Order code Pkg Weight
1 qty (1 pce) g
1 Test plugs DIA 2 mm 0.079 in Black FC2 1SNA007865R2600 100
4 mm² With test socket DIA 4 mm 0.157 in
10 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g
Feed-through With test socket Grey M4/6.4 1SNA115192R0400 50 8.20
DIA 4 mm 0.157 in Beige M4/6.4 1SNA195192R0500 50 8.20
Main technical data IEC UL CSA Nota
Rated voltage 800 V 600 V 600 V
Impulse withstand voltage 8000 V
Protection IP20 NEMA 1
6 mm 0.236 in spacing CE RoHS USR CSA Gost R
Accessories
Description Color Type Order code Pkg Weight 1SNC161093S0201 - Rev. A
1 qty (1 pce) g
1 Test plugs DIA 4 mm 0.157 in White FC4 1SNA167860R0100 10
All the technical data for UL/CSA standard and dimensions in inches are in italic.
Technical data valid for copper conductors only.
ABB SNA series - Terminal blocks | 17
