Page 85 - 1SNC160019C0203_SNA series - Terminal blocks

M4/8.D2.SF screw clamp terminal blocks

For 5 x 20 and 5 x 25 fuses - with blown fuse indicator

8 mm 0.315 in spacing

4 mm² With blown fuse indicator by LED
Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g 2
Fuse With blown fuse indicator Grey M4/8.D2.SFD3 1SNA115936R0500 50 30.00
by LED 24-60 V DC /
110 V AC

Main technical data IEC UL CSA Leakage current :
Rated voltage 500 V 24 V : < 0.5 mA
Impulse withstand voltage 6000 V 110 V : < 2.2 mA
Protection IP20 NEMA 1
8 mm 0.315 in spacing CE RoHS Gost R

4 mm² With blown fuse indicator by neon
12 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g
Fuse With blown fuse indicator Grey M4/8.D2.SFL 1SNA115646R2200 50 30.00
by neon 110-230 V AC

Main technical data IEC UL CSA Leakage current :
Rated voltage 500 V 300 V 250 V 110 V : < 0.5 mA
Impulse withstand voltage 6000 V 230 V : < 0.7 mA
Protection IP20 NEMA 1

CE RoHS USR CNR CSA Gost R
8 mm 0.315 in spacing

4 mm² With blown fuse indicator
12 AWG Ordering details
Description Color Type Order code Pkg Weight
qty (1 pce) g
Fuse With blown fuse indicator Grey M4/8.D2.SFD 1SNA115647R2300 50 30.00
by LED 24 V AC/DC
Main technical data IEC UL CSA Leakage current :
Rated voltage 500 V 250 V 24 V : < 4.5 mA
Impulse withstand voltage 6000 V
Protection IP20 NEMA 1 1SNC161106S0201 - Rev. A

CE RoHS CSA Gost R
8 mm 0.315 in spacing
All the technical data for UL/CSA standard and dimensions in inches are in italic.
Technical data valid for copper conductors only.
ABB SNA series - Terminal blocks | 83
