DS4/6.ADO IDC terminal blocks
Miniblocks ADO - screw clamp - 6 mm 0.236 in spacing

Description
1.5 mm²
– The mini blocks are particularly designed for applications where space is very restricted,
16 AWG – With the TE Connectivity ADO System , experience the fastest and most reliable connection on the market,
®
®
– This solution brings all the benefits of the ADO System and allows installators to connect on standard screw
clamp,
®
– Up to 2 wires per connection in the ADO System connection.
Ordering details Color Type Part Number Pkg Weight
Description
1SNC163080F0014 Feed-through With rib Grey DS4/6.ADO 1SNA299489R0700 pce (1 pce) g
100
5.00
Without rib for TB
Grey
20
5.00
1SNA299556R0100
DSE4/6.ADO
assembly extremity
Main technical data Mounting instructions
IEC UL CSA Rail TH 35-7.5,
TH 35-15
DS4/6.ADO ADO Rigid: Solid/Stranded 0.28-1.5 mm² 22-16 AWG Wire stripping 9.5 mm
Flexible without ferrule 0.34-1.5 mm² length 0.37 in
Screw clamp Rigid: Solid/Stranded 0.2-4 mm² 22-10 AWG Tool Flat screwdriver
Flexible without ferrule 0.22-4 mm² Ø 4 mm
42.3 1.66"
31 1.22" Flexible with insulated ferrule Ø 0.157 in
Gauge A4
Rated current / Rated cross section
17.5 A / 1.5 mm² 20 A / 16 AWG
43 1.69" 35.5 1.39" Rated short-time withstand current (1s) 180 A 600 V Torque 0.5 - 0.8 N.m
4.4 - 7.1 lb.in
Rated voltage
800 V
Impulse withstand voltage
Protection IP20 NEMA 1
20.6 0.81"
The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
0.238" 6 All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
DS
DSE RoHS USR CNR Gost R
6
Notes
6 mm 0.236 in spacing
– End section FEAD1 to be mounted directly on the open part of the terminal
DSE... 5 - 6 - 8 FEAD1
block.
– End terminal block DSE has to be mounted at the end of the terminal
blocks assembly: it reduces its size, because it suppresses the insulation
rib (- 4 mm).
FEAD5
– Nota: This terminal block cannot be accidently located anywhere else into
the terminal block assembly (without locking holes)
– Separator FEAD5 which snaps on the terminal blocks, separates and
makes visible the different parts of the terminal blocks assembly.
DS... 5 - 6 - 8
Accessories
Description Color Type Part Number Pkg Weight
1 2
pce (1 pce) g
1 End stops 10 mm 0.394 in Dark grey BAM4 1SNK900001R0000 50 14.00
5.2 mm 0.205 in BAZ1 1SNK900002R0000 50 5.30
2 End sections 2.5 mm 0.098 in Grey FEAD1 1SNA199421R1600 20 1.30
3 4 3 Jumper bars 2 poles 17.5 A Orange BJADO6-2 1SNA205974R0600 20 1.00
3 poles BJADO6-3 1SNA205975R0700 20 1.00
10 poles BJADO6-10 1SNA205982R2700 10 6.00
4 Lateral jumper bars 2 poles 35 A Grey PC6-2 1SNA113546R1400 10 2.00
3 poles PC6-3 1SNA116536R0500 10 2.00
5 6
4 poles PC6-4 1SNA116537R0600 10 1.00
10 poles PC6-10 1SNA113548R2600 10 8.00
5 Insulating tips For lateral jumper bars type PC... EIP 1SNA113550R2400 10
6 Circuit separators 5 mm 0.197 in Grey FEAD5 1SNA199433R1200 20 1.80
1SNC163028S0201 - Rev. A
7 8 7 Tools Semi automatic tool OUPAD 1SNA178944R0400 1 205.00
Hand tool OUMAD 1SNA179466R0600 1 29.00
8 Terminal block Markers Blank card White RC65 1SNA232000R0000 1 3.60
Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.
Technical data valid for copper conductors only.
